RS PRO 12V ac 2 Output Through Hole PCB Transformer, 6VA
- RS庫存編號:
- 504-559
- 製造商:
- RS PRO
59 現貨庫存，可於3工作日發貨。
已增加
單價 个
HK$222.38
| 單位 | Per unit |
| 1 - 9 | HK$222.38 |
| 10 - 24 | HK$215.72 |
| 25 - 49 | HK$209.03 |
| 50 - 249 | HK$204.57 |
| 250 + | HK$168.36 |
- RS庫存編號:
- 504-559
- 製造商:
- RS PRO
產品概覽和技術數據資料表
法例與合規
- COO (Country of Origin):
- PL
產品詳細資訊
230 Va.c. Primary Transformers
Fully shrouded bobbinsExtra pins for secure board mounting100% electrical and flash testedTested in accordance with BS3535 and EN 60 742
Approvals
8888
Standards
BS3535; EN 60 742
Open Frame - Laminated
PCB mounting mains transformers with a single 230Va.c. or twin 115Va.c. 50/60Hz primary winding. Independent secondary windings may be connected in series or parallel to give a wide range of output voltage and current options.
Double section metric bobbin constructionFull varnish impregnation
規格
Attribute | Value |
|---|---|
| Secondary Voltage Rating | 12V ac |
| Power Rating | 6VA |
| Primary Voltage Rating | 230V ac |
| Number of Outputs | 2 |
| Length | 43mm |
| Width | 36mm |
| Depth | 33mm |
| Dimensions | 43 x 36 x 33mm |
| Weight | 180g |
| Mounting Type | Through Hole |
| Minimum Operating Frequency | 50Hz |
| Maximum Operating Frequency | 60Hz |
