    Hongfa Europe GMBH PCB Mount Power Relay, 5V dc Coil, 10A Switching Current, SPST

    查看所有Power Relays
    可享批量折扣

    小計（1 托盤，共 50 件）**

    HK$1,083.65

    Add to Basket
    選擇或輸入數量
    當前暫無庫存，可於2025/12/14發貨，3 工作日送達。*

    * 交貨日期可能會根據您選擇的數量和交貨地址而變更。

    單位
    每單位
    每托盤**
    50 - 50HK$21.673HK$1,083.65
    100 - 150HK$21.131HK$1,056.55
    200 +HK$20.806HK$1,040.30

    ** 參考價格

    RS庫存編號:
    176-2754
    製造零件編號:
    HF14FF/005-1HTF
    製造商:
    Hongfa Europe GMBH
    透過選取一個或多個屬性來查找類似產品。
    選取全部

    品牌

    Hongfa Europe GMBH

    Coil Voltage

    5V dc

    Contact Configuration

    SPST

    Mounting Type

    PCB Mount

    Switching Current

    10A

    Number of Poles

    1

    Series

    HF14FF

    Latching

    No

    Terminal Type

    PCB Pin

    Maximum Switching Voltage AC

    277V

    Maximum Switching Voltage DC

    30V dc

    Maximum Switching Current AC

    10 A

    Maximum Switching Current DC

    10 A

    Length

    29mm

    Coil Resistance

    47Ω

    Coil Power

    530mW

    Isolation Coil To Contact

    5kV

    Minimum Operating Temperature

    -40°C

    Maximum Operating Temperature

    +70°C

    Height

    26mm

    Life

    1 x 10^7 cycles

    Depth

    13mm

    Contact Material

    Silver Alloy

    Maximum Switching Power AC

    2.77 kVA

    Maximum Switching Power DC

    300 W
