Siemens RCBO, 4A Current Rating, 1P+N Poles, 30mA Trip Sensitivity, Type C, SENTRON Range
- RS庫存編號:
- 187-3285
- 製造零件編號:
- 5SV1316-7KK04
- 製造商:
- Siemens
- RS庫存編號:
- 187-3285
- 製造零件編號:
- 5SV1316-7KK04
- 製造商:
- Siemens
法例與合規
- COO (Country of Origin):
- RO
產品詳細資訊
RCBO compact 1P+N 6 kA type A 30 mA C4
規格
Attribute | Value |
---|---|
Current Rating | 4A |
Number of Poles | 1P+N |
Trip Sensitivity | 30mA |
Tripping Characteristics | Type C |
Range | SENTRON |
Circuit Breaker Type | RCBO |
Series | 5SV1316 |
Rated AC Voltage | 195V |
Earth Leakage Protection Type | A |
Better World Product | Yes |
Better World Claim | Designed for disassembly, Extended product life |
Standards Met | CE |
Break Time | Instantaneous |
Overall Length | 17.6mm |
Terminal Contact Type | Screw |
Overall Depth | 77mm |
Breaking Capacity at Maximum Voltage Rating | 6 kA |
Overall Dimensions | 77 x 18 x 90mm |
Overall Width | 18mm |
