Banner SG-TL70 Series Multiple Effect Beacon Tower, 12 → 30 V dc, LED Bulb, DC, IP65
- RS庫存編號:
- 179-7414
- 製造零件編號:
- SG-TL70-A
- 製造商:
- Banner
- RS庫存編號:
- 179-7414
- 製造零件編號:
- SG-TL70-A
- 製造商:
- Banner
產品概覽和技術數據資料表
法例與合規
- COO (Country of Origin):
- CN
產品詳細資訊
Banner's TL70 Tower Light is a 70 mm, modular LED indicator with extremely bright and uniform light. The modularity gives the user flexibility to customize tower lights as needed and change positions in the field. The TL70 is also available preassembled for easy installation
Light segments have user-selectable solid ON or flashing
Up to six colors, or five colors plus audible, in one device
Rugged, water-resistant housing with UV-stabilized material
Bright, uniform indicator segments appear gray when off to eliminate false indication from ambient light
Several connection options to choose from including M12/Euro-style quick disconnect, cabled, and terminal-wired
Up to six colors, or five colors plus audible, in one device
Rugged, water-resistant housing with UV-stabilized material
Bright, uniform indicator segments appear gray when off to eliminate false indication from ambient light
Several connection options to choose from including M12/Euro-style quick disconnect, cabled, and terminal-wired
規格
Attribute | Value |
|---|---|
| Series | SG-TL70 |
| Component Type | Audible Module |
| Current Type | DC |
| Light Effect | Flashing, Steady |
| Lamp Included | Yes |
| Bulb Type | LED |
| Supply Voltage | 12 → 30 V dc |
| Minimum Decibel | 84dB |
| Maximum Decibel | 92dB |
| Height | 72mm |
| Base Diameter | 70mm |
| IP Rating | IP65 |
| Housing Colour | Black |
| Maximum Temperature | +50°C |
| Minimum Temperature | -40°C |
