BEL POWER SOLUTIONS INC Switching Regulator, Screw Mount, 5.1V dc Output Voltage, 7 → 40V dc Input Voltage, 8A
- RS庫存編號:
- 466-7556
- 製造零件編號:
- PSB5A8-2IRG
- 製造商:
- BEL POWER SOLUTIONS INC
- RS庫存編號:
- 466-7556
- 製造零件編號:
- PSB5A8-2IRG
- 製造商:
- BEL POWER SOLUTIONS INC
產品概覽和技術數據資料表
法例與合規
不相容
- COO (Country of Origin):
- SK
產品詳細資訊
Positive Switching Regulators
Wide input voltage range
High current output
High efficiency
Low input to output differential voltage
Very good dynamic properties
Input undervoltage lock-out
Parallel configurations possible
Continuous no-load and short-circuit proof
No derating
High current output
High efficiency
Low input to output differential voltage
Very good dynamic properties
Input undervoltage lock-out
Parallel configurations possible
Continuous no-load and short-circuit proof
No derating
Standards
UL 1950, UL 1012, EN60950
規格
Attribute | Value |
|---|---|
| Output Voltage | 5.1V dc |
| Output Current | 8A |
| Input Voltage | 7 → 40V dc |
| Mounting Type | Screw Mount |
| Number of Outputs | 1 |
| Power Rating | 40.8W |
| Minimum Temperature | -10°C |
| Maximum Temperature | +50°C |
| Width | 69mm |
| Length | 106mm |
| Depth | 32.2mm |
