Tempatron TT4801 Series DIN Rail, Panel Mount Timer Relay, 110V ac, 2-Contact, 6 s → 6h, 1-Function, DPDT
- RS庫存編號:
- 217-1334
- 製造商:
- Tempatron
- RS庫存編號:
- 217-1334
- 製造商:
- Tempatron
產品概覽和技術數據資料表
法例與合規
- COO (Country of Origin):
- GB
產品詳細資訊
Electronic
Function 111
8 pin
Time range selectable by screwdriver from a rotary switch on the side of the module
Lockable dial to prevent tampering
DPDT contact configuration
AgCdO contact material
8 pin
Time range selectable by screwdriver from a rotary switch on the side of the module
Lockable dial to prevent tampering
DPDT contact configuration
AgCdO contact material
Standards
EN 50081-1, EN 50082-1, EN 61010-1.
規格
Attribute | Value |
|---|---|
| Supply Voltage | 110V ac |
| Mounting Type | DIN Rail, Panel Mount |
| Mode of Operation | ON Delay Energise |
| Time Range | 6 s → 6h |
| Number of Contacts | 2 |
| Number of Timer Functions | Single |
| Contact Configuration | DPDT |
| Time Increment | Hours, Seconds |
| Maximum Current | 5A |
| Maximum Voltage | 30 V dc, 240V ac |
| Terminal Type | 8-Pin Connector |
| Switch Configuration | DPDT |
| Width | 48mm |
| Power Supply | External |
| Series | TT4801 |
| Length | 48mm |
| Depth | 106mm |
| Maximum Operating Temperature | +60°C |
| Time Delay | (Reset) 100ms |
| Minimum Operating Temperature | -10°C |
