Cypress Semiconductor CYUSB3304-68LTXI, USB Controller, 4-Channel, 5Gbit/s, USB 2.0, USB 3.0, 1.2 V, 3.3 V, 68-Pin QFN
- RS庫存編號:
- 182-0112
- 製造零件編號:
- CYUSB3304-68LTXI
- 製造商:
- Cypress Semiconductor
260 現貨庫存，可於3工作日發貨。
已增加
單價 个（每套 260）
HK$37.806
| 單位 | Per unit | Per Tray* |
| 260 - 260 | HK$37.806 | HK$9,829.56 |
| 520 - 780 | HK$37.05 | HK$9,633.00 |
| 1040 + | HK$36.309 | HK$9,440.34 |
| * 參考價格 | ||
- RS庫存編號:
- 182-0112
- 製造零件編號:
- CYUSB3304-68LTXI
- 製造商:
- Cypress Semiconductor
法例與合規
產品詳細資訊
HX3 is a family of USB 3.0 hub controllers compliant with the USB 3.0 specification revision 1.0. HX3 supports SuperSpeed (SS),Hi-Speed (HS), Full-Speed (FS), and Low-Speed (LS) on all the ports. It has integrated termination, pull-up, and pull-down resistors, and supports configuration options through pin-straps to reduce the overall BOM of the system. HX3 includes the following Cypress-proprietary features:Shared Link™: Enables extra downstream (DS) ports for on-board connections in embedded applications Ghost Charge™: Enables charging of devices connected to the DS ports when no host is connected on the upstream (US) port
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
規格
Attribute | Value |
|---|---|
| Number of Transceivers | 4 |
| Data Rate | 5Gbit/s |
| IC Type | Controller IC |
| Protocols Supported | USB 2.0, USB 3.0 |
| Power Supply Type | Single |
| ESD Protection | Yes |
| Typical Single Supply Voltage | 1.2 V, 3.3 V |
| Mounting Type | Surface Mount |
| Package Type | QFN |
| Pin Count | 68 |
| Dimensions | 8 x 8 x 0.95mm |
| Height | 0.95mm |
| Length | 8mm |
| Maximum Operating Temperature | +85 °C |
| Minimum Operating Temperature | -40 °C |
| Width | 8mm |
