- RS庫存編號:
- 308-584
- 製造零件編號:
- CSR1504A
- 製造商:
- United Automation
14 現貨庫存,可於3工作日發貨。
已增加
單價 个
HK$369.96
單位 | Per unit |
1 - 4 | HK$369.96 |
5 - 9 | HK$355.16 |
10 - 19 | HK$340.36 |
20 + | HK$332.96 |
- RS庫存編號:
- 308-584
- 製造零件編號:
- CSR1504A
- 製造商:
- United Automation
產品概覽和技術數據資料表
法例與合規
- COO (Country of Origin):
- GB
產品詳細資訊
CSR Power Regulator 6A, 10A & 15A, United Automation
United Automation CSR Power Regulator integrated chips (IC) control single phase mains driven loads of 6A, 10A and 15A. The Solid-state phase controlled power regulator needs external 220 k or 250 k linear potentiometers (not supplied) and controls the power into a resistive load from 0% to 98%. Applications include resistive heating elements like quartz lamps, ovens and dryers as well as some inductive loads such as transformers, fans and motors.
Transistor style housing with isolated heat sink tab
Applications
Suitable for coventional resistive heating elements such as ovens, quartz lamps, moulders and dryers. They are also suitable for many inductive loads such as transformers, fans and motors.
規格
Attribute | Value |
---|---|
Regulator Type | Linear Voltage |
Maximum Output Current | 15A |
Output Voltage | 230 V |
Mounting Type | Through Hole |
Pin Count | 3 |
Output Type | Adjustable |
Dimensions | 17.5 x 7.6 x 29.3mm |
Maximum Input Voltage | 230 V |
Height | 29.3mm |
Minimum Operating Temperature | 0 °C |
Maximum Operating Temperature | +70 °C |
Length | 17.5mm |
Width | 7.6mm |
