BK Precision BK4065 4065 Arbitrary Waveform Generator 40 MHz, 160 MHz

  • RS庫存編號 878-2151
  • 製造零件編號 BK4065
  • 製造商 BK Precision
產品概覽和技術數據資料表
法例與合規
不相容
COO (Country of Origin): CH
產品詳細資訊

B&K Precision Series 4060 Dual Channel Function/Arbitrary Waveform Generators

B&K Precision Series 4060 dual channel function/arbitrary waveform generators generate stable and precise sine, square, triangle, pulse and arbitrary waveforms. They have an easy-to-read colour display and intuitive user interface with numeric keypad. Features include linear/logarithmic sweep, built-in counter, extensive modulation and triggering capabilities, a continuously variable DC offset and a high performance 14-bit, 500 MSa/s arbitrary waveform generator.

14-bit, 500 MSa/s, 512k point arbitrary waveform generator
Two independent channels with one button synchronization
Large 4.3-inch LCD color display
Linear and logarithmic sweep
AM/DSB-AM/ASK/FM/FSK/PM/PWM modulation functions
Variable DC offset
Highly adjustable pulse duty cycle from 0.0001% to 99.9999%
Internal/external triggering
Gate and burst mode
36 built-in predefined arbitrary waveforms
Store/recall up to 10 instrument settings and 32 user-defined arbitrary waveforms
Built-in counter
USB device port (USBTMC-compliant) with front panel USB host port
Short circuit output protection

Supplied with

Getting started manual, full instruction manual on CD, AC power cord, USB type A-to-type B cable, certificate of calibration

規格
Attribute Value
Maximum Frequency 40 MHz, 160 MHz
Minimum Frequency 1 μHz
Maximum Frequency Triangle Ramps 4MHz
Minimum Frequency Triangle Ramps 1µHz
Maximum Sampling Frequency 500Msps
Resolution 4 Digit
Maximum Pulse Width 1.000.000s
Minimum Pulse Width 12ns
Arbitrary Waveforms Yes
Sweep Linear, Logarithmic, Up or Down
Weight 2.8kg
Rise - Fall Time 6 ns → 6 s
Height 105mm
Length 261mm
Display Type TFT LCD (480 x 272)
Width 344mm
Inputs Modulation In
Connector Type BNC
Data Entry Keypad
Interface Type GPIB, USB
Dimensions 261 x 344 x 105mm
Maximum Storage 32
Maximum Operating Temperature +40°C
Model Number p 4065
Minimum Operating Temperature 0°C
Waveform Memory per Channel 16k points
2 現貨庫存,可於3工作日發貨。
單價 個
HK$ 15,362.50
(不含稅)
單位
Per unit
1 +
HK$15,362.50
