Superior Electric 15A, Green Binding Post With Brass Contacts and Gold Plated - 9.52mm Hole Diameter
- RS庫存編號:
- 923-4619
- 製造零件編號:
- BP21GN-1 PKG
- 製造商:
- Superior Electric
此產品已停售
- RS庫存編號:
- 923-4619
- 製造零件編號:
- BP21GN-1 PKG
- 製造商:
- Superior Electric
產品概覽和技術數據資料表
法例與合規
- COO (Country of Origin):
- US
產品詳細資訊
5-WAY® Series Single Binding Posts
Superior Electric 5-WAY series Single Binding Posts are designed for fast, accurate mounting on 19 mm centres. Current ratings and basic dimensions are the same as single types. Available in red, white, blue, yellow, black and green thumbnut colour choices in standard, miniature and 10-32 stud styles. Insulating parts black only. Current carrying parts are gold or nickel plated brass for improved conductivity and corrosion resistance.
Superior Electric
規格
Attribute | Value |
|---|---|
| Colour | Green |
| Contact Material | Brass |
| Contact Plating | Gold |
| Current Rating | 15A |
| Voltage Rating | 1kV |
| Gender | Female |
| Height Above Panel | 23.5mm |
| Maximum Panel Thickness | 6.35mm |
| Hole Diameter | 9.52mm |
