RS PRO 6VA 2 Output Chassis Mounting Transformer, 15V ac

RS庫存編號:: 504-773
製造商:: RS PRO

RS PRO 6VA 2 Output Chassis Mounting Transformer, 15V ac

36 現貨庫存，可於3工作日發貨。

HK$244.32

單位	Per unit
1 - 9	HK$244.32
10 - 24	HK$237.00
25 - 49	HK$229.65
50 - 249	HK$224.79
250 +	HK$185.00

RS庫存編號:: 504-773
製造商:: RS PRO

產品概覽和技術數據資料表

RS PRO Datasheet

法例與合規

COO (Country of Origin):: PL

產品詳細資訊

Chassis Mount, Clamp Construction, 230Vac, 6V to 50V

Chassis mounting low voltage mains transformers with a single 230Va.c. 50/60Hz primary winding. The two independent secondary windings may be connected in series or parallel to give a wide range of output voltage and current options.

Double section bobbin construction
Fully shrouded bobbins
Full varnish impregnation
Two hole fixing wrap-over clamps
Solder tag terminations
Optional terminal shrouds
100% electrical and flash tested
Tested in accordance with BS3535 and EN 60 742

Chassis Mount, Clamp Construction, 230Vac, 6VA to 50VA

Chassis mounting low voltage mains transformers with a single 230Va.c. 50/60Hz primary winding. The two independent secondary windings may be connected in series or parallel to give a wide range of output voltage and current options.

Features and Benefits

"Double section bobbin construction
Fully shrouded bobbins
Full varnish impregnation
Two hole fixing wrap-over clamps
Solder tag terminations
Optional terminal shrouds (example 503-912 )
100% electrical and flash tested
Tested in accordance with BS3535 and EN 60 742"

Standards

BS3535; EN 60 742

規格

Attribute	Value
Primary Voltage Rating	230V ac
Secondary Voltage Rating	15V ac
Power Rating	6VA
Number of Outputs	2
Mounting Type	Clamp Mount
Length	45mm
Width	40mm
Depth	37mm
Dimensions	45 x 40 x 37mm
Fixing Hole Diameter	4 x 5.5mm
Weight	200g
Minimum Operating Frequency	50Hz
Maximum Operating Frequency	60Hz
