暫時無法供應
我們不知道此物品是否會到貨，因為製造商正在對其逐步停產。
- RS庫存編號:
- 165-740
- 製造零件編號:
- 0 309 510
- 製造商:
- Hengstler
規格
產品概覽和技術數據資料表
法例與合規
產品詳細資訊
透過選取一個或多個屬性來查找類似產品。
選取全部 | 屬性 | 值 |
|---|---|---|
| 品牌 | Hengstler | |
| Function | Counter | |
| Reset Method | No Reset | |
| Number of Digits | 5 | |
| Count Direction | Top Going | |
| Digit Height | 4.2 mm | |
| Shaft Speed Maximum | 500spm | |
| Drive Shaft Diameter | 3mm | |
| 選取全部 | ||
|---|---|---|
品牌 Hengstler | ||
Function Counter | ||
Reset Method No Reset | ||
Number of Digits 5 | ||
Count Direction Top Going | ||
Digit Height 4.2 mm | ||
Shaft Speed Maximum 500spm | ||
Drive Shaft Diameter 3mm | ||
- COO (Country of Origin):
- SK
Flush Mount Stroke Counters - 309 Series
Miniature flush mount adding counter
5 digits, 4.2mm high
500 strokes per minute
Right hand stroke
Non-resettable
Switching distance: 46° to 49°
Dimensions: H24 x W32 x D22.5mm
5 digits, 4.2mm high
500 strokes per minute
Right hand stroke
Non-resettable
Switching distance: 46° to 49°
Dimensions: H24 x W32 x D22.5mm
