IMI Norgren B72G Filter Regulator, 40μm, G 1/4, Semi Automatic
- RS庫存編號:
- 239-0686
- 製造零件編號:
- B72G-2GK-ST3-RMN
- 製造商:
- IMI Norgren
查看所有Filter Regulators
- RS庫存編號:
- 239-0686
- 製造零件編號:
- B72G-2GK-ST3-RMN
- 製造商:
- IMI Norgren
不適用
- COO (Country of Origin):
- GB
法例與合規
不適用
- COO (Country of Origin):
- GB
產品詳細資訊
IMI Norgren Semi-Automatic Drain Filter Regulator, 0.3 to 10 Bar, 40μm Filtration Size - B72G Series - B72G-2GK-ST3-RMN
Use this combined filter regulator unit from IMI Norgren to keep compressed air clean and at a constant pressure. Its filter removes dust, oil and water from your air supply to reduce excessive wear on pneumatic equipment. The regulator keeps output pressure constant for improved efficiency and has a wide operating range of 0.3 to 10 bar for use in high-pressure and low-pressure systems. A lockable adjusting knob means you can securely set the parameters of the regulator without worrying about it being altered. For easy maintenance, its robust polycarbonate (PC) filter bowl is transparent, so you can quickly see when it needs to be drained.
Features & Benefits
Quick-release bayonet bowl that's easy to remove and replace
Suitable for modular or in-line installation for versatility
Die-cast zinc body is durable and corrosion-resistant
Wide operating temperature range of -20°C to +50°C for use in demanding conditions
Suitable for modular or in-line installation for versatility
Die-cast zinc body is durable and corrosion-resistant
Wide operating temperature range of -20°C to +50°C for use in demanding conditions
Applications
Mining and minerals processing
Chemical industry
Textile and printing industries
Chemical industry
Textile and printing industries
Where can I mount this filter regulator?
This versatile filter regulator unit is suitable for panel or wall mounting. It's compatible with panels that are 0 to 4mm thick and needs a mounting hole with a diameter of 40mm.
規格
Attribute | Value |
Manufacturer Series | B72G |
Port Connection | G 1/4 |
Drain Type | Semi Automatic |
Filtration Size | 40µm |
Pressure Gauge Port | Rc 1/8 |
Pressure Gauge Port Thread Size | 1/8 in |
Port Connection Thread Size | 1/4 in |
Maximum Operating Pressure | 10 bar |
Maximum Ambient Operating Temperature | +50°C |
Minimum Operating Pressure | 0.3bar |
Ambient Operating Temperature Range | -34 → +50°C |
Minimum Ambient Operating Temperature | -34°C |
Port Connection Thread Standard | G |
Pressure Gauge Port Thread Standard | Rc |
Bowl Material | Polycarbonate |
