Craig & Derricott Switch Disconnector, 2 Pole, 32A Max Current
- RS庫存編號:
- 254-8871
- 製造零件編號:
- EDDKG323N
- 製造商:
- Craig & Derricott
1 現貨庫存，可於3工作日發貨。
單價 个
HK$591.01
| 單位 | Per unit |
| 1 + | HK$591.01 |
- RS庫存編號:
- 254-8871
- 製造零件編號:
- EDDKG323N
- 製造商:
- Craig & Derricott
產品概覽和技術數據資料表
法例與合規
- COO (Country of Origin):
- GB
產品詳細資訊
The Craig & Derricott switch disconnector has pad lockable handle which allows for an insertion of up to three padlocks in the ’Off’ position thus preventing the isolator being switched to the ’On’ position. This unit has the ability to add a 1N/O + 1 N/C auxiliary contact block.
Die-cast aluminium enclosed isolation equipment with sealing up to IP66
Cable entries 2 x M20 top, bottom and back
Compliant to IEC / BS EN 60947-3
Cable entries 2 x M20 top, bottom and back
Compliant to IEC / BS EN 60947-3
規格
Attribute | Value |
|---|---|
| Number of Poles | 2 |
| Maximum Current | 32A |
| Enclosed/Not Enclosed | Enclosed |
| Normal State Configuration | 1NC/1NO |
| Range | 323 |
| Series | EDDKG |
| Throw Configuration | DP |
