- RS庫存編號:
- 175-7751
- 製造零件編號:
- gen4-uLCD-43D
- 製造商:
- 4D Systems
當前暫無庫存,可於2024/6/3發貨,3 工作日送達。
已增加
單價 个
HK$660.95
單位 | Per unit |
1 - 9 | HK$660.95 |
10 - 24 | HK$634.51 |
25 - 49 | HK$621.82 |
50 + | HK$609.38 |
- RS庫存編號:
- 175-7751
- 製造零件編號:
- gen4-uLCD-43D
- 製造商:
- 4D Systems
法例與合規
- COO (Country of Origin):
- AU
產品詳細資訊
4D Systems LCD Display Module
The 4D Systems LCD 4.3in display module with an integrated 4-wire resistive touch panel is designed specifically for ease of integration and use, with careful consideration for space requirements and functionality. This module is embedded with PICASO processor. It has 480 x 272 pixels resolution and 500cd/m² brightness. The display module offers an active viewing area of the width of 53.86mm and a height of 95.04mm.
Features and Benefits
• Built-in extensive 4DGL graphics and system library functions
• Dedicated PWM audio pin driven by WAV files from micro-SD card and for sound generation for an external amplifier
• Display full colour images, animation, icons and video clips
• DOS compatible file access (FAT16 format) as well as low level access to card memory
• On-board latch type micro-SD memory card connector for multimedia storage and data logging purposes
• RGB 65K true to life colours
• Universal intelligent LCD-TFT display module powered by the Picaso processor
• Dedicated PWM audio pin driven by WAV files from micro-SD card and for sound generation for an external amplifier
• Display full colour images, animation, icons and video clips
• DOS compatible file access (FAT16 format) as well as low level access to card memory
• On-board latch type micro-SD memory card connector for multimedia storage and data logging purposes
• RGB 65K true to life colours
• Universal intelligent LCD-TFT display module powered by the Picaso processor
Certifications
• CE compliant
• REACH compliant
• REACH compliant
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
規格
Attribute | Value |
---|---|
Diagonal Display Size | 4.3in |
Resolution | 480 x 272pixels |
Viewing Area Dimensions | 95 x 54mm |
Supply Voltage | 4 → 5.5 V |
Backlight Type | LCD |
Display Mode | Transmissive |
AC or DC Input Voltage | dc |
Dimensions | 69.3 x 6.7 x 127.6mm |
Display Matrix Technology | TFT |
Minimum Operating Temperature | -20°C |
Maximum Operating Temperature | +70°C |
Brightness | 500cd/m² |
Series | gen4 |
Display Type | TFT LCD |
Contrast Ratio | 500:1 |
Viewing Area Height | 95.04mm |
Voltage Rating | 5.5V |
Viewing Area Width | 53.86mm |
Power Supply Included | Yes |
Depth | 6.7mm |
Current Rating | 310mA |
Operating Temperature Range | -20 → +70°C |
Width | 69.3mm |
Height | 127.6mm |
