Wachendorff Incremental Incremental Encoder, 64 ppr, HTL Inverted Signal, Solid Type, 6mm Shaft
- RS庫存編號:
- 470-737
- 製造零件編號:
- 24A643MK7
- 製造商:
- Wachendorff
- RS庫存編號:
- 470-737
- 製造零件編號:
- 24A643MK7
- 製造商:
- Wachendorff
產品概覽和技術數據資料表
法例與合規
- COO (Country of Origin):
- DE
產品詳細資訊
WDG24A rotary encoder - incremental, 24 mm
Very small design for tough conditions
Authorised bearing loads as for large variants
High IP65 protection rating
Authorised bearing loads as for large variants
High IP65 protection rating
Areas of application:
Small electric motors
Driverless transport systems
Storage technology
Handling technology
Installation technology
Driverless transport systems
Storage technology
Handling technology
Installation technology
Approvals
UL
規格
Attribute | Value |
|---|---|
| Encoder Technology | Incremental |
| Pulses Per Revolution | 64 |
| Maximum Revolutions | 12000rpm |
| Output Signal Type | HTL Inverted |
| Shaft Type | Solid |
| Supply Voltage | 10 → 30 V dc |
| Shaft Diameter | 6mm |
| Steps Per Revolution | 64Steps |
| IP Rating | IP65 |
| Mounting Type | Synchro Flange |
