Bourns PEC16 Series Incremental Encoder, 24 ppr, Quadrature Signal, Solid Type, 6mm Shaft
- RS庫存編號:
- 181-4425
- 製造零件編號:
- PEC16-4220F-N0024
- 製造商:
- Bourns
查看所有Motion Control Sensors
800 現貨庫存，可於3工作日發貨。
單價 個 (以毎盒：200)
HK$8.163
| 單位 | Per unit | Per Box* |
| 200 - 800 | HK$8.163 | HK$1,632.60 |
| 1000 + | HK$7.347 | HK$1,469.40 |
| * 參考價格 | ||
- RS庫存編號:
- 181-4425
- 製造零件編號:
- PEC16-4220F-N0024
- 製造商:
- Bourns
產品概覽和技術數據資料表
法例與合規
產品詳細資訊
Compact design,long life and high reliability
Low cost compared to optical type encoders
Available in a wide variety of configurations to meet many user requirements
Low cost compared to optical type encoders
Available in a wide variety of configurations to meet many user requirements
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
規格
| Attribute | Value |
| Encoder Technology | Incremental |
| Pulses Per Revolution | 24 |
| Output Signal Type | Quadrature |
| Shaft Type | Solid |
| Supply Voltage | 5 V dc |
| Shaft Diameter | 6mm |
| Resolution | 2 Bit |
| IP Rating | IP40 |
| Overall Height | 17.7mm |
| Overall Width | 16mm |
| Overall Depth | 31.5mm |
| Minimum Operating Temperature | -30°C |
| Maximum Operating Temperature | +70°C |
| Mounting Type | Panel Mount |
| Series | PEC16 |
| Current Rating | 1 A @ 5 V dc |
