    Omron Incremental Encoder, 360 ppr, Radial Type

    RS庫存編號:
    386-0063
    製造零件編號:
    E6B2-CWZ6C 360P/R 2M
    製造商:
    Omron
    Omron

    此圖片僅供參考,請參閲產品詳細資訊及規格

    查看所有Motion Control Sensors
    5 現貨庫存,可於7工作日發貨。
    Add to Basket
    單位

    已增加

    單價 個

    HK$3,656.38

    單位Per unit
    1 - 9HK$3,656.38
    10 +HK$3,412.67
    RS庫存編號:
    386-0063
    製造零件編號:
    E6B2-CWZ6C 360P/R 2M
    製造商:
    Omron

    不適用

    COO (Country of Origin):
    CN

    產品概覽和技術數據資料表


    法例與合規

    不適用

    COO (Country of Origin):
    CN

    產品詳細資訊

    E6B2 Incremental Rotary Encoder


    General purpose incremental rotary encoders for use in positioning applications


    Easy to adjust zero index (phase Z) with origin indicating function
    Rugged construction: 6mm diameter shaft with radial load rating of 3kgf & axial load rating of 2kgf
    Protected against output short circuit and reversed connections



    規格

    AttributeValue
    Encoder TechnologyIncremental
    Pulses Per Revolution360
    Maximum Revolutions6000rpm
    Shaft TypeRadial
    Supply Voltage5 → 24 V dc
    Overall Height59mm
    Minimum Operating Temperature-25°C
    Maximum Operating Temperature+85°C
    Switching Frequency100 kHz
