製造零件編號

Hengstler AC58 Series Absolute Absolute Encoder, Gray, SSI Signal, Solid Type, 10mm Shaft

RS庫存編號:: 480-0517
製造零件編號:: RC58/0012EK.42SGB
製造商:: Hengstler

Hengstler AC58 Series Absolute Absolute Encoder, Gray, SSI Signal, Solid Type, 10mm Shaft

小計（1 件）*

HK$3,747.20

訂單超過 HK$250.00 免費送貨

有庫存

2 件準備從其他地點送貨

**需要更多嗎？**輸入您需要的數量，然後按一下「查看送貨日期」以查詢更多庫存和送貨詳細資訊。

單位	每單位
1 +	HK$3,747.20

* 參考價格

RS庫存編號:: 480-0517
製造零件編號:: RC58/0012EK.42SGB
製造商:: Hengstler

規格

產品概覽和技術數據資料表

法例與合規

產品詳細資訊

透過選取一個或多個屬性來查找類似產品。

選取全部	屬性	值
	品牌	Hengstler
	Encoder Technology	Absolute
	Series	AC58
	Maximum Revolutions	10000rpm
	Output Signal Type	Gray, SSI
	Shaft Type	Solid
	Supply Voltage	10 → 30 V dc
	Shaft Diameter	10mm
	Resolution	12 bit
	IP Rating	IP64, IP67
	Interface	SSI-Gray
	Minimum Operating Temperature	-40°C
	Maximum Operating Temperature	+100°C

	選取全部
	品牌 Hengstler
	Encoder Technology Absolute
	Series AC58
	Maximum Revolutions 10000rpm
	Output Signal Type Gray, SSI
	Shaft Type Solid
	Supply Voltage 10 → 30 V dc
	Shaft Diameter 10mm
	Resolution 12 bit
	IP Rating IP64, IP67
	Interface SSI-Gray
	Minimum Operating Temperature -40°C
	Maximum Operating Temperature +100°C

Datasheet

豁免

COO (Country of Origin):: DE

Rotary transducer AC58 - absolute, single turn, 58 mm

"ACURO Industry" series
Single turn design
Integrated safety and monitoring system
Magnetically insensitive
Maintenance-free as no battery
Compact dimensions
Preset key
Diagnostic LEDs

Hengstler

Radial cable termination
Alarm, A, B, N output
Encoders: OptoAsic technology for greater reliability
Pulse shape: Square wave, 1:1 duty cycle

Hengstler AC58 Series Absolute Absolute Encoder, Gray, SSI Signal, Solid Type, 10mm Shaft

訂單超過 HK$250.00 免費送貨

Rotary transducer AC58 - absolute, single turn, 58 mm
