- RS庫存編號:
- 171-8477
- 製造零件編號:
- N24-T110100E0
- 製造商:
- Lumel
- RS庫存編號:
- 171-8477
- 製造零件編號:
- N24-T110100E0
- 製造商:
- Lumel
法例與合規
- COO (Country of Origin):
- PL
產品詳細資訊
Lumel LED Digital Panel Multi-Function Meter
The Lumel N24 series 4-digit LED digital panel multi-function meter. It is designed to measure the temperature. Its service temperature ranges between -10°C and 55°C. Possible configuration of parameters is through the PD14 programmer and the free delivered LPConfig program.
Features and Benefits
Automatic or manual compensation
Measurement of averaging time
Precision of displayed results
Recounting of indications
Measuring ranges are -50 → +1200°C, -50 → +150°C, -50 → 1370°C, -50 → 400°C
Measurement of averaging time
Precision of displayed results
Recounting of indications
Measuring ranges are -50 → +1200°C, -50 → +150°C, -50 → 1370°C, -50 → 400°C
Applications
Commercial applications
Industrial applications
Industrial applications
Certifications
CE certified
EN 61000-6-2 accredited
EN 61000-6-4 accredited
EN 61010-1 accredited
IP65 rated
EN 61000-6-2 accredited
EN 61000-6-4 accredited
EN 61010-1 accredited
IP65 rated
規格
Attribute | Value |
---|---|
Properties Measured | Temperature |
Display Type | LED |
Cutout Height | 92mm |
Cutout Width | 45mm |
Number of Digits | 4 |
Depth | 64mm |
Digit Height | 20 mm |
Minimum Temperature | -10°C |
Maximum Temperature | +55°C |
Measurement Range | -50 → +1200 °C, -50 → +150 °C, -50 → 1370 °C, -50 → 400 °C |
Minimum Measurement | -50 °C |
Approvals | CE Certified |
Series | N24 |
Meter Type | Digital |
