RS PRO 16A 115/250 V ac 50 → 60Hz, Chassis Mount Power Line Filter, Fast-On, Single Phase
- RS庫存編號:
- 286-7239
- 製造商:
- RS PRO
可享批量折扣
小計（1 件）**
HK$174.46
79 現貨庫存，可於3工作日發貨。*
* 交貨日期可能會根據您選擇的數量和交貨地址而變更。
訂單金額滿 HK$250.00 即可享受 免費 送貨服務
即時庫存查詢
單位 | 每單位 |
|---|---|
| 1 - 9 | HK$174.46 |
| 10 - 24 | HK$162.22 |
| 25 - 49 | HK$150.89 |
| 50 - 99 | HK$140.37 |
| 100 + | HK$130.53 |
** 參考價格
- RS庫存編號:
- 286-7239
- 製造商:
- RS PRO
透過選取一個或多個屬性來查找類似產品。
選取全部 | 屬性 | 值 |
|---|---|---|
| 品牌 | RS PRO | |
| Maximum Current Rating | 16A | |
| Maximum Voltage Rating | 115/250 V ac | |
| Mounting Type | Chassis Mount | |
| Termination Style | Fast-On | |
| Number of Phases | 1 | |
| Number of Stages | Single Stage | |
| Operating Frequency | 50 → 60Hz | |
| Length | 63mm | |
| Depth | 51mm | |
| Height | 29mm | |
| Capacitance | 0.1µF | |
| Dimensions | 63 x 51 x 29mm | |
| Inductance | 2 x 0.7mH | |
| Leakage Current | 0.5/1.0mA | |
| Minimum Operating Temperature | -25°C | |
| Maximum Operating Temperature | +85°C | |
| Resistance | 1MΩ | |
選取全部 | ||
|---|---|---|
品牌 RS PRO | ||
Maximum Current Rating 16A | ||
Maximum Voltage Rating 115/250 V ac | ||
Mounting Type Chassis Mount | ||
Termination Style Fast-On | ||
Number of Phases 1 | ||
Number of Stages Single Stage | ||
Operating Frequency 50 → 60Hz | ||
Length 63mm | ||
Depth 51mm | ||
Height 29mm | ||
Capacitance 0.1µF | ||
Dimensions 63 x 51 x 29mm | ||
Inductance 2 x 0.7mH | ||
Leakage Current 0.5/1.0mA | ||
Minimum Operating Temperature -25°C | ||
Maximum Operating Temperature +85°C | ||
Resistance 1MΩ | ||
