Accuride, 45kg Max Load
- RS庫存編號:
- 876-5979
- 製造零件編號:
- DB3832-0055EC-B-RS
- 製造商:
- Accuride
- RS庫存編號:
- 876-5979
- 製造零件編號:
- DB3832-0055EC-B-RS
- 製造商:
- Accuride
產品概覽和技術數據資料表
法例與合規
- COO (Country of Origin):
- MX
產品詳細資訊
DB3832EC-B Soft Close Drawer Slide
Soft close drawer slide
Steel black zinc plated
Load rating up to 45 kg
100% extension
12.7 mm slide thickness
Front disconnect
Hold-in
Cam drawer adjust
Steel black zinc plated
Load rating up to 45 kg
100% extension
12.7 mm slide thickness
Front disconnect
Hold-in
Cam drawer adjust
規格
Attribute | Value |
|---|---|
| Type | Telescopic Slide |
| Maximum Load | 45kg |
| Width | 12.7mm |
| Height | 46mm |
| Slide Length Closed | 550mm |
| Series | DB3832 |
