KOA, CN 100kΩ ±5% Isolated Resistor Array, 4 Resistors, 1206 (3216M), Concave
- RS庫存編號:
- 172-9573
- 製造零件編號:
- CN2B4TTE104J
- 製造商:
- KOA
可享批量折扣
小計（1 包，共 100 件）*
HK$334.00
訂單超過 HK$250.00 免費送貨
正在逐步停售
- 最終 2,900 個，準備發貨
單位 | 每單位 | 每包* |
|---|---|---|
| 100 - 100 | HK$3.34 | HK$334.00 |
| 200 - 400 | HK$3.173 | HK$317.30 |
| 500 + | HK$3.015 | HK$301.50 |
* 參考價格
- RS庫存編號:
- 172-9573
- 製造零件編號:
- CN2B4TTE104J
- 製造商:
- KOA
規格
產品概覽和技術數據資料表
法例與合規
產品詳細資訊
透過選取一個或多個屬性來查找類似產品。
選取全部 | 屬性 | 值 |
|---|---|---|
| 品牌 | KOA | |
| Resistance | 100kΩ | |
| Resistor Type | Array | |
| Number of Resistors | 4 | |
| Package/Case | 1206 (3216M) | |
| Termination Style | Concave | |
| Tolerance | ±5% | |
| Automotive Standard | AEC-Q200 | |
| Case Style | Moulded | |
| Power Rating per Resistor | 0.125W | |
| Circuit Designator | ISOL | |
| Length | 5.08mm | |
| Depth | 3.2mm | |
| Height | 0.6mm | |
| Dimensions | 5.08 x 3.2 x 0.6mm | |
| Series | CN | |
| Number of Terminals | 8 | |
| Minimum Operating Temperature | -55°C | |
| Temperature Coefficient | ±200ppm/°C | |
| Maximum Operating Temperature | +155°C | |
| 選取全部 | ||
|---|---|---|
品牌 KOA | ||
Resistance 100kΩ | ||
Resistor Type Array | ||
Number of Resistors 4 | ||
Package/Case 1206 (3216M) | ||
Termination Style Concave | ||
Tolerance ±5% | ||
Automotive Standard AEC-Q200 | ||
Case Style Moulded | ||
Power Rating per Resistor 0.125W | ||
Circuit Designator ISOL | ||
Length 5.08mm | ||
Depth 3.2mm | ||
Height 0.6mm | ||
Dimensions 5.08 x 3.2 x 0.6mm | ||
Series CN | ||
Number of Terminals 8 | ||
Minimum Operating Temperature -55°C | ||
Temperature Coefficient ±200ppm/°C | ||
Maximum Operating Temperature +155°C | ||
- COO (Country of Origin):
- JP
Concave termination with square corners resistor array
Less board space than individual chips
Isolated resistor elements
Isolated resistor elements
