Maxim Integrated Switching Regulator, Surface Mount, 3 → 10V dc Output Voltage, 1.5 → 10V dc Input
- RS庫存編號:
- 190-7901P
- 製造零件編號:
- ICL7660CUA+
- 製造商:
- Maxim Integrated
查看所有Switching Regulators
- RS庫存編號:
- 190-7901P
- 製造零件編號:
- ICL7660CUA+
- 製造商:
- Maxim Integrated
產品概覽和技術數據資料表
法例與合規
產品詳細資訊
Miniature μMAX Package
1.5V to 10.0V Operating Supply Voltage Range
98% Typical Power-Conversion Efficiency
Invert, Double, Divide, or Multiply Input Voltages
BOOST Pin Increases Switching Frequencies (MAX1044)
No-Load Supply Current: 200μA Max at 5V
No External Diode Required for Higher-Voltage Operation
Applications
-5V Supply from +5V Logic Supply
Data Acquisition
Handheld Instruments (PDAs, Palmtops)
Op-Amp Power Supplies
Panel Meters
Personal Communications Equipment
Portable Telephones
1.5V to 10.0V Operating Supply Voltage Range
98% Typical Power-Conversion Efficiency
Invert, Double, Divide, or Multiply Input Voltages
BOOST Pin Increases Switching Frequencies (MAX1044)
No-Load Supply Current: 200μA Max at 5V
No External Diode Required for Higher-Voltage Operation
Applications
-5V Supply from +5V Logic Supply
Data Acquisition
Handheld Instruments (PDAs, Palmtops)
Op-Amp Power Supplies
Panel Meters
Personal Communications Equipment
Portable Telephones
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
規格
| Attribute | Value |
| Output Voltage | 3 → 10V dc |
| Output Current | 200µA |
| Input Voltage | 1.5 → 10V dc |
| Mounting Type | Surface Mount |
| Number of Outputs | 1 |
| Efficiency | 99.9 (Typ.)% |
| Maximum Temperature | +70°C |
| Minimum Temperature | 0°C |
| Width | 3.1mm |
| Depth | 0.95mm |
| Length | 3.1mm |
| Special Features | No External Diode Required for Higher-Voltage Operation |
| Application | -5V Supply from +5V Logic Supply, Data-Acquisition, EIA/TIA-232E and, EIA/TIA-562 Power Supplies, Handheld Instruments, Op-Amp Power Supplies, Panel Meters, Personal Communications Equipment, Portable Telephones, Systems |
