Helukabel Twisted Pair Cable, 2 Cores, 1.5 mm², 16 AWG, 100m, Mains Cable
- RS庫存編號:
- 284-4261
- Distrelec 貨號:
- 301-01-256
- 製造零件編號:
- 29485
- 製造商:
- Helukabel
不可供應
RS 不再對此產品進貨。
替代產品
該產品我們目前不提供。 這是我們推薦的替代產品。
1 Reel of 100 Metre(s)
HK$774.50
- RS庫存編號:
- 284-4261
- Distrelec 貨號:
- 301-01-256
- 製造零件編號:
- 29485
- 製造商:
- Helukabel
規格
產品概覽和技術數據資料表
法例與合規
產品詳細資訊
透過選取一個或多個屬性來查找類似產品。
選取全部 | 屬性 | 值 |
|---|---|---|
| 品牌 | Helukabel | |
| Cross Sectional Area | 1.5 mm² | |
| Number of Cores | 2 | |
| American Wire Gauge | 16 AWG | |
| Length | 100m | |
| Sheath Colour | White | |
| Cable Type | Mains | |
| 選取全部 | ||
|---|---|---|
品牌 Helukabel | ||
Cross Sectional Area 1.5 mm² | ||
Number of Cores 2 | ||
American Wire Gauge 16 AWG | ||
Length 100m | ||
Sheath Colour White | ||
Cable Type Mains | ||
- COO (Country of Origin):
- DE
The main cable is an EPR/PUR-insulated power cable compliant with DIN VDE 0282 part 10 and HD 22.10 S1 standards. It features a plain copper conductor, stranded according to DIN VDE 0295 cl. 5, BS 6360 cl. 5, and HD 383 cl. 5. The insulating jacket is made of rubber compound EI6, meeting DIN VDE 0282 part 1 specifications. Core identification follows DIN VDE 0293-308 and HD308 S2 standards, with a green-yellow earth core positioned in the outer layer. Cores are stranded in layers with optimal lay-length, and inner fill compound is permissible. This cable is suitable for various power transmission applications where durability and reliability are essential.
Test voltage 2000 V
PVC outer jacket
Rohs compliant
PVC outer jacket
Rohs compliant
