Motor Starters

A motor starter is a device for motor control applications and is used to start and stop a motor. A starter is an electromechanical switch similar to a relay, the main difference being that a starter contains a contactor and overload protection to prevent electrical overloading of the motor.

Types of Motor Starter

  • DOL Starters - Direct On Line (DOL) or across the line starters are the most common general purpose starter. A magnetic contactor connects the full voltage of the power supply directly to the motor with an overload relay for protection against short circuit, energizing the coil pulls the contactors together to close the circuit and start the device. They are used for motors that are only required to run in one direction at a single speed.
  • Reversing DOL Starters - these motor starters can run a motor either forwards or backwards. These three-button starters are particularly useful for conveyor based machinery, where reversing the direction is sometimes necessary.
  • Star Delta Starter - a reduced voltage motor starter designed to control a three-phase induction motor, the windings in this starter are switched between star and delta connections to start the motor. A star delta circuit will have a contactor configuration within the relay of. triple pole (star) and double throw (delta).
  • Soft Starter - typically used to control AC electric motors a soft starter works by helping reduce the torque and load in the power up and electrical current surges that are typical with motors during their start-up phase. It uses solid-state switches to control the voltage as well as the starting current supplied.

...
顯示內容 隱藏內容

篩選條件

正在檢視 1 - 20,共 1254 項產品
Results per page
Description Price Power Rating Motor Starter Type Range Voltage Rating IP Rating Current Rating Phase Number of Poles Motor Starter Functionality Reversibility Additional Features Overall Length Enclosure Overall Width
RS庫存編號 609-7713
製造零件編號LE1M35V7
HK$496.61
單位
7.5 kW DOL - 400 V ac IP65 - - 3P Automatic - - 160mm Yes 78mm
RS庫存編號 133-028
製造零件編號48ADS1XRS
BrandEaton
HK$1,027.82
單位
9 kW DOL - 415 V ac IP54 - 3 - Automatic - - 223mm Yes 141mm
RS庫存編號 725-5507
BrandRS PRO
HK$386.90
單位
5.5 kW DOL - 400 V ac IP65 9 → 14 A 3 3P Automatic - Disconnect Switch Not Included 193mm Yes 88mm
RS庫存編號 272-454
製造零件編號LUCA05FU
HK$784.33
單位
3 kW DOL - 690 V ac IP40 - 3 3P - - - - - -
RS庫存編號 710-6458
製造零件編號ATS22C17Q
HK$17,262.96
單位
90 kW - - 440 V IP00 170 A 3 - - - - 269.5mm - 150mm
RS庫存編號 563-087
製造零件編號2297057
HK$1,829.21
單位
24 V DC - - - - 9 A - - - - - - - -
RS庫存編號 719-1734
製造零件編號2900582
HK$1,228.73
單位
0.18 kW - Contactron hybrid motor starter - - - - - - - - - - -
RS庫存編號 710-6461
製造零件編號ATS22C48Q
HK$47,395.12
單位
250 kW - - 440 V IP00 480 A 3 - - - - 339.7mm - 304mm
RS庫存編號 725-5503
BrandRS PRO
HK$385.07
單位
5.5 kW DOL - 230 V ac IP65 9 → 14 A 3 3P Automatic - Disconnect Switch Not Included 193mm Yes 88mm
RS庫存編號 493-8921
HK$1,150.12
單位
5.5 kW - TeSys - - - - - - - - - - -
RS庫存編號 133-056
製造零件編號48ADSA1XRS
BrandEaton
HK$3,334.04
單位
9 kW DOL - 415 V ac IP54 - 3 - Automatic - Disconnect Switch Included 260mm Yes 221.5mm
RS庫存編號 330-5358
製造零件編號SSC-25
HK$497.05
單位
- - - 230 V - 25 A 1 - - - - - - -
RS庫存編號 608-7019
製造零件編號ATS48C17Q
HK$15,186.34
單位
90 kW - - 415 V IP00 170 A 3 - - - - 265mm - 200mm
RS庫存編號 609-7505
製造零件編號LC3D12AP7
HK$3,729.44
單位
11 kW Star Delta - 440 V ac - - - 3P - - Mechanical Interlock Included 124mm - 143mm
RS庫存編號 351-4748
製造零件編號LE1GBKO55N7
HK$684.11
單位
5.5 kW DOL - 415 V ac IP65 - - - Automatic - - 212mm Yes 124mm
RS庫存編號 725-5516
BrandRS PRO
HK$462.75
單位
7.5 kW DOL - 230 V ac IP65 13 → 18 A 3 3P Automatic - Disconnect Switch Not Included 193mm Yes 88mm
RS庫存編號 783-9228
製造零件編號3RM1202-1AA04
BrandSiemens
HK$1,622.65
單位
3 kW - SIRIUS - - - - - - - - - - -
RS庫存編號 917-6538
製造零件編號LT6CT1001
HK$572.00
單位
- - - - - - - - - - - - - -
RS庫存編號 535-2261
製造零件編號278408 & SDAINLM55(110V50HZ,120V60HZ)
BrandEaton
HK$5,048.13
單位
30 kW Star Delta - 110 V ac IP55 - 3 - Automatic - - 85mm - 158mm
RS庫存編號 729-8863
製造零件編號BA9010 (HK)
BrandDold
HK$52,052.65
單位
5.5 kW - - 400 V ac IP30 - 3 - - - - 74mm - 45mm
