Fibre Optic Sensors

Fibre optic sensors are a type of proximity sensor that have an optical fibre connected to a light source to allow for detection in tight spaces or where a small profile is beneficial. The optical fibre is a transparent fibre made of glass (silica) or plastic with a diameter slightly thicker than a human hair, this fibre transmits light between the two ends to produce an electrical signal.

How Fibre Optic Sensors Work

A fibre-optic sensor system is a technology that consists of a fibre-optic cable connected to a remote sensor, or amplifier. The sensor emits, receives, and converts the light energy into an electrical signal. The optical cable is the mechanical component that transports the light into and out of areas that are either too space constrained or too hostile back to the sensor.

Uses of Fibre Optic Sensors

Fibre optic sensors are used in a number of different sensing applications. In mechanical properties testing, fibre optical sensors are used to measure mechanical strain. They can also be used to measure acceleration, velocity, pressure, temperature and displacement.


...
顯示內容 隱藏內容

篩選條件

正在檢視 61 - 80,共 200 項產品
Results per page
Description Price Detection Range Output Type Fibre Optic Type Terminal Type Response Time Light Source Communication Protocol Electrical Connection Power Consumption Switching Frequency IP Rating Housing Material Supply Voltage Length
RS庫存編號 848-5816
製造零件編號D10UPFP
BrandBanner
HK$3,083.31
單位
- PNP Plastic - 2.5 ms Visible Green, Visible Red - Cable - - IP50 ABS/PC 15 → 24 V dc 68.1mm
RS庫存編號 377-8447
BrandRS PRO
HK$1,810.49
單位
- PNP - - 500 μs Red LED - Cable - 1 kHz - PE, Plastic 12 → 24 V dc 10mm
RS庫存編號 812-8361
製造零件編號FX-LE1
BrandPanasonic
HK$128.84
單位
- - - - - - - - - - - - - 9.2mm
RS庫存編號 152-631
製造零件編號E3X-MDA41 OMS
BrandOmron
HK$2,972.57
單位
- PNP - - 1 ms, 4 ms, 130 μs, 450 μs Red LED - Cable 1.08 W - IP50 PBT 12 → 24 V dc 74.3mm
RS庫存編號 820-9930
製造零件編號E32-T16PR
BrandOmron
HK$2,936.76
單位
4000 mm NPN, PNP Plastic - - - - - - - IP50 - - 27mm
RS庫存編號 842-8608
製造零件編號LL3-TB02
BrandSick
HK$432.68
單位
- - Glass, Plastic - - - - Cable - - - - - 2m
RS庫存編號 177-8708
製造零件編號DF-G2-PS-2M
BrandBanner
HK$1,777.57
單位
1100 mm PNP - Cable 10 (Super High Speed) μs, 15 (High Speed) μs, 50 (Fast) μs, 250 (Standard) μs, 500 (Medium Range) μs, 1000 (Long Range) μs, 2000 (Long Range with Immunity) μs Red LED - 4-Wire 960 mW - IP50 Thermoplastic 10 → 30 V dc 86.9mm
RS庫存編號 178-0202
製造零件編號E32DC200E
BrandOmron
HK$879.09
單位
22 (Super High Speed Mode) mm, 80 (Standard Mode) mm, 130 (High Resolution Mode) mm - Plastic Wire Lead - - - Cable - - IP67 PE - 11mm
全新
RS庫存編號 213-1737
製造零件編號GLL170T-B434
BrandSick
HK$1,210.02
單位
0 to 400 (Proximity System) mm, 0 → 1320 (Through-Beam System) mm NPN, PNP Glass, Plastic 4-Pin 5.00E-05 seconds - - Male Connector M8 - 10 kHz IP66 Plastic 10 → 30 V dc 34.6mm
全新
RS庫存編號 213-1839
製造零件編號WLL180T-N432
BrandSick
HK$1,705.03
單位
0 to 1400 (Proximity System) mm, 0 → 18000 (Through-Beam System) mm NPN Glass, Plastic 4-Wire 1.60E-05 seconds - - Cable - 31.2 kHz IP50 Plastic 12 → 24 V dc 34.6mm
RS庫存編號 786-5747
製造零件編號E3NXFA212M
BrandOmron
HK$2,285.57
單位
- NPN - Pre-Wired 1 (Standard Mode) ms, 16 (Giga Power Mode) ms, 32 (Super High Speed Mode) μs, 250 (High Speed Mode) μs Red LED - Pre-Wired Cable 1.08 W - - PC 10 → 30 V dc 104.8mm
RS庫存編號 820-9918
製造零件編號E32-DC200B4
BrandOmron
HK$1,379.99
單位
- - Plastic - - - - - - - IP67 Nickel Plated Brass - 17mm
RS庫存編號 177-8716
製造零件編號PIT46U
BrandBanner
HK$505.95
單位
- - Plastic M2.5, M4 - - - - - - - Polyethylene - 2.011m
全新
RS庫存編號 213-1735
製造零件編號GLL170T-B333
BrandSick
HK$1,210.02
單位
0 to 400 (Proximity System) mm, 0 → 1320 (Through-Beam System) mm NPN, PNP Glass, Plastic 3-Pin 5.00E-05 seconds - - Connector M8 - 10 kHz IP66 Plastic 10 → 30 V dc 34.6mm
RS庫存編號 175-0063
製造零件編號E3NXMA112MOMS
BrandOmron
HK$2,641.91
單位
- NPN - Pre-Wired 1 ms, 16 ms, 100 μs, 450 μs LED - - 960 mW - IP50, IP54 Polycarbonate 30 V dc 104.5mm
RS庫存編號 205-7092
製造零件編號E32L25
BrandOmron
HK$1,036.65
單位
3.3 mm - Plastic Wire Lead - - - Cable - - IP67 PE - 20mm
RS庫存編號 764-5414
製造零件編號E3X-HD11 2M
BrandOmron
HK$1,627.35
單位
- NPN Glass Pre-Wired 1 (Standard Mode) ms, 16 (Giga Power Mode) ms, 50 (Super High Speed Mode) μs, 250 (High Speed Mode) μs Red LED - Pre-Wired Cable 720 mW - IP50 PC 12 → 24 V dc -
RS庫存編號 510-3564
製造零件編號LMR18-23-05-K2
HK$1,086.33
單位
- - Glass Screw 1 ms Red LED - - - 500 Hz IP40 Nickel Plated Brass 10 → 30 V dc 500mm
RS庫存編號 764-3843
製造零件編號SU18-16/40A/110/115/126A
HK$1,360.46
單位
450 mm NPN, PNP Glass, Plastic - 160 μs LED - PVC Cable - 3 kHz IP50 PC 10 → 30 V dc 35mm
RS庫存編號 812-8235
製造零件編號FD-61
BrandPanasonic
HK$366.40
單位
450 mm - Plastic M6 Screw 25 μs - - - - - IP64 - - 17mm
