RS PRO 2 Output 50 VA Chassis Mount Transformer, 5 V ac, IECBSEN 615581, ASNZS 61558..6, RoHS, ASNZS 61558.1, CE,
- RS庫存編號:
- 504-612
- Distrelec 貨號:
- 304-04-321
- 製造商:
- RS PRO
可享批量折扣
查看批量定價選項小計（1 件）*
HK$216.80
訂單超過 HK$250.00 免費送貨
正在逐步停售
- 最終 1 個，準備發貨
單位 | 每單位 |
|---|---|
| 1 - 9 | HK$216.80 |
| 10 - 24 | HK$210.30 |
| 25 - 49 | HK$203.80 |
| 50 - 249 | HK$199.50 |
| 250 + | HK$164.20 |
* 參考價格
Sponsored
- RS庫存編號:
- 504-612
- Distrelec 貨號:
- 304-04-321
- 製造商:
- RS PRO
規格
產品概覽和技術數據資料表
法例與合規
產品詳細資訊
透過選取一個或多個屬性來查找類似產品。
選取全部 | 屬性 | 值 |
|---|---|---|
| 品牌 | RS PRO | |
| Product Type | Chassis Mount Transformer | |
| Primary Voltage | 230 V ac | |
| Secondary Voltage | 5 V ac | |
| Number of Outputs | 2 | |
| Power | 50VA | |
| Minimum Operating Temperature | -30°C | |
| Maximum Operating Temperature | 130°C | |
| Minimum Operating Frequency | 50Hz | |
| Length | 59mm | |
| Width | 57mm | |
| Depth | 50mm | |
| Weight | 210g | |
| Standards/Approvals | IECBSEN 615581, ASNZS 61558..6, RoHS, ASNZS 61558.1, CE, IECBSEN 615586 | |
| Maximum Operating Frequency | 60Hz | |
| 選取全部 | ||
|---|---|---|
品牌 RS PRO | ||
Product Type Chassis Mount Transformer | ||
Primary Voltage 230 V ac | ||
Secondary Voltage 5 V ac | ||
Number of Outputs 2 | ||
Power 50VA | ||
Minimum Operating Temperature -30°C | ||
Maximum Operating Temperature 130°C | ||
Minimum Operating Frequency 50Hz | ||
Length 59mm | ||
Width 57mm | ||
Depth 50mm | ||
Weight 210g | ||
Standards/Approvals IECBSEN 615581, ASNZS 61558..6, RoHS, ASNZS 61558.1, CE, IECBSEN 615586 | ||
Maximum Operating Frequency 60Hz | ||
- COO (Country of Origin):
- PL
Chassis Mount, Clamp Construction, 230Vac, 6VA to 50VA
Chassis mounting low voltage mains transformers with a single 230Va.c. 50/60Hz primary winding. The two independent secondary windings may be connected in series or parallel to give a wide range of output voltage and current options.
Features and Benefits
"Double section bobbin construction
Fully shrouded bobbins
Full varnish impregnation
Two hole fixing wrap-over clamps
Solder tag terminations
Optional terminal shrouds (example 503-912 )
100% electrical and flash tested
Tested in accordance with BS3535 and EN 60 742"
Standards
BS3535; EN 60 742
