LEM LV Series Current Transformer 14 A 12V, 15 V
- RS庫存編號:
- 286-361
- Distrelec 貨號:
- 176-96-503
- 製造零件編號:
- LV 25-P
- 製造商:
- LEM
可享批量折扣
查看批量定價選項小計（1 件）*
HK$351.70
訂單超過 HK$250.00 免費送貨
有庫存
- 加上 155 件從 2026年9月28日 起發貨
- 加上 75 件從 2026年10月05日 起發貨
**需要更多嗎？**輸入您需要的數量，然後按一下「查看送貨日期」以查詢更多庫存和送貨詳細資訊。
單位 | 每單位 |
|---|---|
| 1 - 5 | HK$351.70 |
| 6 - 11 | HK$342.90 |
| 12 + | HK$336.90 |
* 參考價格
- RS庫存編號:
- 286-361
- Distrelec 貨號:
- 176-96-503
- 製造零件編號:
- LV 25-P
- 製造商:
- LEM
規格
產品概覽和技術數據資料表
法例與合規
產品詳細資訊
透過選取一個或多個屬性來查找類似產品。
選取全部 | 屬性 | 值 |
|---|---|---|
| 品牌 | LEM | |
| Product Type | Current Transformer | |
| Series | LV | |
| Secondary Current | 25mA | |
| Terminal Type | Wire | |
| Minimum Operating Temperature | 0°C | |
| Primary Current | 14A | |
| Maximum Operating Temperature | 70°C | |
| Standards/Approvals | CE, EN 50178: 1997, IEC 61010-1, UL | |
| Length | 16.45mm | |
| Depth | 29.2mm | |
| Weight | 22g | |
| Width | 26mm | |
| Mount Type | PCB | |
| Supply Voltage | 12V, 15V | |
| 選取全部 | ||
|---|---|---|
品牌 LEM | ||
Product Type Current Transformer | ||
Series LV | ||
Secondary Current 25mA | ||
Terminal Type Wire | ||
Minimum Operating Temperature 0°C | ||
Primary Current 14A | ||
Maximum Operating Temperature 70°C | ||
Standards/Approvals CE, EN 50178: 1997, IEC 61010-1, UL | ||
Length 16.45mm | ||
Depth 29.2mm | ||
Weight 22g | ||
Width 26mm | ||
Mount Type PCB | ||
Supply Voltage 12V, 15V | ||
- COO (Country of Origin):
- CN
Features & Benefits
Self - extinguishing plastic case
Ideal for measuring voltages associated with AC/DC impulse circuits
An external resistor must be inserted in series with the primary circuit to measure a voltage
Instantaneous output
Suitable for d.c. power supplies, UPS's, instruments, metering and relay systems
Closed loop operation
Insulated plastic case
High level of accuracy
Linearity
Low thermal drift
High bandwidth
External interference immunity
Common mode low disturbance
PCB Mount
For the electronic measurement of currents, DC, AC, pulsed, providing galvanic separation between the primary circuit and the secondary circuit.
A Hall effect device, which provides galvanic isolation between primary and secondary circuits
Self extinguishing plastic case
Ideal for measuring voltages associated with a.c. and d.c. impluse circuits
An external resistor must inserted in series with the primary circuit to measure a voltage
Instantaneous output
Suitable for d.c. power supplies, UPS's, instruments, metering and relay systems
Closed loop operation
