Schneider Electric Resi9 Electronic Circuit Breaker 16A R9PDCS, Clip-On Type C

The Schneider Electric Residual Current Breaker with Overcurrent Protection (RCBO) is designed for distribution applications in AC networks. It features a 3P + N (three poles plus neutral) configuration, with the neutral positioned on the left, and protects three poles. The breaker has a rated current of 16A at 30°C, conforming to EN/IEC 61009-2-1 standards. It uses thermal-magnetic trip unit technology with a C-curve characteristic for effective overcurrent protection. The earth-leakage sensitivity is 30 mA, with instantaneous tripping and Type A-SI (Super Immunised) protection to reduce nuisance tripping.

Mechanical durability of 20000 cycles
Electrical durability of 7500 cycles
RoHS compliant
