Microchip LAN9255-I/ZMX020 ARM 32-bit Cortex-M4 Microcontroller, ARM, 20MHz, 1.024 MB SRAM, 128-Pin TQFP
- RS庫存編號:
- 234-3727P
- 製造零件編號:
- LAN9255-I/ZMX020
- 製造商:
- Microchip
可享批量折扣
小計 10 件 (以盤裝提供)*
HK$1,469.30
訂單超過 HK$250.00 免費送貨
有庫存
- 215 件準備從其他地點送貨
**需要更多嗎？**輸入您需要的數量，然後按一下「查看送貨日期」以查詢更多庫存和送貨詳細資訊。
單位 | 每單位 |
|---|---|
| 10 - 24 | HK$146.93 |
| 25 - 49 | HK$143.99 |
| 50 + | HK$141.11 |
* 參考價格
- RS庫存編號:
- 234-3727P
- 製造零件編號:
- LAN9255-I/ZMX020
- 製造商:
- Microchip
規格
產品概覽和技術數據資料表
法例與合規
產品詳細資訊
透過選取一個或多個屬性來查找類似產品。
選取全部 | 屬性 | 值 |
|---|---|---|
| 品牌 | Microchip | |
| Product Type | Microcontroller | |
| Series | EtherCAT | |
| Package Type | TQFP | |
| Mount Type | Surface | |
| Pin Count | 128 | |
| Device Core | ARM 32 Bit Cortex M4 | |
| Program Memory Size | 1.024MB | |
| Maximum Clock Frequency | 20MHz | |
| RAM Size | 256kB | |
| Maximum Supply Voltage | 3.3V | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 85°C | |
| Standards/Approvals | No | |
| DACs | 2 x 12 Bit | |
| Width | 14 mm | |
| Length | 14mm | |
| Height | 0.4mm | |
| Minimum Supply Voltage | 1.2V | |
| ADCs | 2 x 12 Bit | |
| Program Memory Type | SRAM | |
| Automotive Standard | No | |
| 選取全部 | ||
|---|---|---|
品牌 Microchip | ||
Product Type Microcontroller | ||
Series EtherCAT | ||
Package Type TQFP | ||
Mount Type Surface | ||
Pin Count 128 | ||
Device Core ARM 32 Bit Cortex M4 | ||
Program Memory Size 1.024MB | ||
Maximum Clock Frequency 20MHz | ||
RAM Size 256kB | ||
Maximum Supply Voltage 3.3V | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 85°C | ||
Standards/Approvals No | ||
DACs 2 x 12 Bit | ||
Width 14 mm | ||
Length 14mm | ||
Height 0.4mm | ||
Minimum Supply Voltage 1.2V | ||
ADCs 2 x 12 Bit | ||
Program Memory Type SRAM | ||
Automotive Standard No | ||
The Microchip Technology 2/3 port EtherCAT®device controller with 8 fieldbus memory management units and eight sync managers has integrated 32-bit Cortex-M4 microcontroller unit with 1 Msps 12-bit ADC, SQSPI, USB LS/FS host and device, Ethernet MAC and PTC. It comes with 128 pin count, 1.024 MB program memory size and 20MHz maximum frequency. It is used in applications such as motor motion control, process/factory automation, communication modules & Interface cards, sensors, hydraulic and pneumatic valve systems.
SRAM program memory
Integrated 100mbps Ethernet transceivers
Host bus Interface
Three power down levels
Power-on Reset (POR) and Brown-out detection
Internal and external clock options
Idle, Standby, Hibernate, Backup, and Off sleep modes
EEPROM emulation
Enhanced EtherCAT cycle time
Multifunction GPIOs
Ability to use low cost 25MHz crystal for reduced BOM
RoHS compliant
