Wurth Elektronik Surface PCB Transformer, UL60950
- RS庫存編號:
- 299-018
- 製造零件編號:
- 750510505
- 製造商:
- Wurth Elektronik
小計（1 管，共 10 件）*
HK$1,158.50
訂單超過 HK$250.00 免費送貨
有庫存
- 加上 9 件從 2026年8月24日 起發貨
**需要更多嗎？**輸入您需要的數量，然後按一下「查看送貨日期」以查詢更多庫存和送貨詳細資訊。
管 | 每管 | 每單位* |
|---|---|---|
| 1 + | HK$1,158.50 | HK$115.85 |
* 參考價格
- RS庫存編號:
- 299-018
- 製造零件編號:
- 750510505
- 製造商:
- Wurth Elektronik
規格
產品概覽和技術數據資料表
法例與合規
產品詳細資訊
透過選取一個或多個屬性來查找類似產品。
選取全部 | 屬性 | 值 |
|---|---|---|
| 品牌 | Wurth Elektronik | |
| Product Type | PCB Transformer | |
| Primary Voltage | 400 V | |
| Length | 20.45mm | |
| Width | 20.45mm | |
| Depth | 10.16mm | |
| Weight | 3.8g | |
| Mount Type | Surface | |
| Minimum Operating Temperature | -40°C | |
| Maximum Operating Temperature | 125°C | |
| Standards/Approvals | UL60950 | |
| 選取全部 | ||
|---|---|---|
品牌 Wurth Elektronik | ||
Product Type PCB Transformer | ||
Primary Voltage 400 V | ||
Length 20.45mm | ||
Width 20.45mm | ||
Depth 10.16mm | ||
Weight 3.8g | ||
Mount Type Surface | ||
Minimum Operating Temperature -40°C | ||
Maximum Operating Temperature 125°C | ||
Standards/Approvals UL60950 | ||
- COO (Country of Origin):
- CN
The Wurth Elektronik component has D.C. resistance values of 0.050 ohms max, 0.035 ohms max, and 0.125 ohms max with an inductance of 870 uH ±30% and leakage inductance of 600 nH type, 1.5 uH max It features a dielectric strength of 5000 VAC for 1 second and 4000 VAC for 1 minute with a turns ratio of 1:1 ±1%
Reinforced insulation for primary circuit
Working voltage of 400 VDC
