Vishay VCNL36825T Proximity Sensor 200 mm -0.3 V 3.8V 6 Surface Mount
- RS庫存編號:
- 244-4835
- 製造零件編號:
- VCNL36825T
- 製造商:
- Vishay
此圖片僅供參考,請參閲產品詳細資訊及規格
享受批量購買折扣
額外添加50件可節省HK$15.00
查看批量定價選項小計(1 包,共 5 件)*
HK$52.30
訂單超過 HK$250.00 免費送貨
最後的 RS 庫存
- 最終 4,095 個,準備發貨
單位 | 每單位 | 每包* | 節省 |
|---|---|---|---|
| 5 - 45 | HK$10.46 | HK$52.30 | - |
| 50 - 95 | HK$10.16 | HK$50.80 | HK$15.00 |
| 100 - 495 | HK$9.82 | HK$49.10 | HK$64.00 |
| 500 - 1995 | HK$9.54 | HK$47.70 | HK$460.00 |
| 2000 + | HK$9.26 | HK$46.30 | HK$2,400.00 |
* 參考價格
- RS庫存編號:
- 244-4835
- 製造零件編號:
- VCNL36825T
- 製造商:
- Vishay
規格
產品概覽和技術數據資料表
法例與合規
產品詳細資訊
透過選取一個或多個屬性來查找類似產品。
選取全部 | 屬性 | 值 |
|---|---|---|
| 品牌 | Vishay | |
| Product Type | Proximity Sensor | |
| Maximum Switching Frequency | 400kHz | |
| Maximum Output Current | 300μA | |
| Maximum Output Voltage | 3.6V | |
| Sensing Distance | 200mm | |
| Mount Type | Surface | |
| Package Type | Surface Mount | |
| Pin Count | 6 | |
| Length | 2mm | |
| Width | 1.25mm | |
| Height | 500μm | |
| Maximum Operating Temperature | 85°C | |
| Minimum Operating Temperature | -40°C | |
| Minimum Supply Voltage | -0.3V | |
| Automotive Standard | No | |
| Series | VCNL36825T | |
| Maximum Supply Voltage | 3.8V | |
| 選取全部 | ||
|---|---|---|
品牌 Vishay | ||
Product Type Proximity Sensor | ||
Maximum Switching Frequency 400kHz | ||
Maximum Output Current 300μA | ||
Maximum Output Voltage 3.6V | ||
Sensing Distance 200mm | ||
Mount Type Surface | ||
Package Type Surface Mount | ||
Pin Count 6 | ||
Length 2mm | ||
Width 1.25mm | ||
Height 500μm | ||
Maximum Operating Temperature 85°C | ||
Minimum Operating Temperature -40°C | ||
Minimum Supply Voltage -0.3V | ||
Automotive Standard No | ||
Series VCNL36825T | ||
Maximum Supply Voltage 3.8V | ||
The Vishay proximity sensor (PS) and a VCSEL into one small package. It incorporates photodiodes, amplifiers, and analog to digital converting circuits into a single chip by CMOS process. PS programmable interrupt features of individual high and low thresholds offers the best utilization of resource and power saving on the microcontroller.
Package type is surface mount
Interrupt function
1.6 mm single hole opening design
Low power consumption
Temperature compensation is -40 °C to +85 °C
