ABB RCBO, 6A Current Rating, 1P+N Poles, 30mA Trip Sensitivity, Type C, System Pro M Compact Range

RS庫存編號:: 201-6936
Distrelec 貨號:: 304-08-584
製造零件編號:: 2CSR275180R1064 DS201 M C6 A30
製造商:: ABB

ABB RCBO, 6A Current Rating, 1P+N Poles, 30mA Trip Sensitivity, Type C, System Pro M Compact Range

查看所有RCBOs

小計（1 件）*

HK$1,205.10

訂單超過 HK$250.00 免費送貨

有庫存

3 件準備從其他地點送貨
加上 7 件從 2026年1月09日起發貨
加上 8 件從 2026年2月06日起發貨

**需要更多嗎？**輸入您需要的數量，然後按一下「查看送貨日期」以查詢更多庫存和送貨詳細資訊。

單位	每單位
1 +	HK$1,205.10

* 參考價格

RS庫存編號:: 201-6936
Distrelec 貨號:: 304-08-584
製造零件編號:: 2CSR275180R1064 DS201 M C6 A30
製造商:: ABB

規格

產品概覽和技術數據資料表

法例與合規

產品詳細資訊

透過選取一個或多個屬性來查找類似產品。

選取全部	屬性	值
	品牌	ABB
	Current Rating	6A
	Number of Poles	1P+N
	Range	System Pro M Compact
	Trip Sensitivity	30mA
	Series	DS201
	Circuit Breaker Type	RCBO
	Tripping Characteristics	Type C
	Rated AC Voltage	230/240V
	Mounting Style	DIN Rail Mount
	Earth Leakage Protection Type	A
	Overall Dimensions	85 x 69 x 35mm
	Reset Actuator Type	Toggle Switch
	Terminal Contact Type	Screw
	Overall Width	35mm
	Breaking Capacity at Maximum Voltage Rating	10 kA
	Overall Depth	69mm
	Standards Met	RoHS Compliant
	Overall Length	85mm
	Special Features	Short Circuit Protection

	選取全部
	品牌 ABB
	Current Rating 6A
	Number of Poles 1P+N
	Range System Pro M Compact
	Trip Sensitivity 30mA
	Series DS201
	Circuit Breaker Type RCBO
	Tripping Characteristics Type C
	Rated AC Voltage 230/240V
	Mounting Style DIN Rail Mount
	Earth Leakage Protection Type A
	Overall Dimensions 85 x 69 x 35mm
	Reset Actuator Type Toggle Switch
	Terminal Contact Type Screw
	Overall Width 35mm
	Breaking Capacity at Maximum Voltage Rating 10 kA
	Overall Depth 69mm
	Standards Met RoHS Compliant
	Overall Length 85mm
	Special Features Short Circuit Protection

ABB RCBO, Rail Mounting, 2.6W Total Power Loss - DS201 Series - 2CSR275180R1064 DS201 M C6 A30

Cut electrical supply issues off in a flash with this RCBO from ABB. By breaking for current leakage and overloads, it provides solid protection against common power faults. Thanks to its instantaneous function, the unit trips straight away to minimise the risk of hardware damage. Resets are done with a flick of the front-facing toggle lever, meaning your system is up and running again quickly and downtime is minimised. Mounting this breaker is speedy, thanks to tool-free installation on a DIN rail.

Features & Benefits

• Short-circuit breaking capacity of 10kA for effective surge protection
• Labelled poles clearly identify connections for simple wiring
• Electrical service life of 10,000 operations, providing long-term safeguarding
• Colour-coded status indicator, signalling contact positions at a glance
• Screw terminals to secure conductor connections against movement

Applications

• Packaging lines
• Engineering workshops
• Plastic processing

How do I know when this RCBO has tripped for a power fault?

A blue indicator appears on this unit's lever when it detects a fault, so it's easy to spot issues with your electrical supply as they occur.
