Hongfa Europe GMBH Surface Mount Signal Relay, 12V dc Coil, 2A Switching Current, DPDT
- RS庫存編號:
- 176-2956
- 製造零件編號:
- HFD3/012-S
- 製造商:
- Hongfa Europe GMBH
查看所有Signal Relays
80 現貨庫存，可於3工作日發貨。
單價 /個 (每包:5個)
HK$20.274
| 單位 | Per unit | Per Pack* |
| 5 - 5 | HK$20.274 | HK$101.37 |
| 10 - 15 | HK$19.828 | HK$99.14 |
| 20 + | HK$19.404 | HK$97.02 |
| * 參考價格 | ||
- RS庫存編號:
- 176-2956
- 製造零件編號:
- HFD3/012-S
- 製造商:
- Hongfa Europe GMBH
產品概覽和技術數據資料表
法例與合規
- COO (Country of Origin):
- CN
產品詳細資訊
Hongfa DPDT Non-Latching Relay
The Hongfa DPDT 2-pole non-latching surface mount relay is actuated with the help of a 12VDC coil and up to 4A DC/AC current through the coil for the relay to switch positions. This relay is a subminiature signal type relay. It can be used in single coil or double coil latching configuration. This relay has silver alloy contacts for high electrical endurance.
Features and Benefits
• Environmental-friendly product
• SMT and DIP types available
• Isolation voltage between the coil and contacts is 2.5KV
• Service temperature range between -40°C and 85°C
• High mechanical endurance and long life of 100M cycles
• High surge withstand voltage up to 2500VAC
• Resistant to vibration and abrasion
• SMT and DIP types available
• Isolation voltage between the coil and contacts is 2.5KV
• Service temperature range between -40°C and 85°C
• High mechanical endurance and long life of 100M cycles
• High surge withstand voltage up to 2500VAC
• Resistant to vibration and abrasion
Applications
• Used as a control device
• Automotive industry
• Household appliances
• Industrial machinery
• Telecommunication
• Automotive industry
• Household appliances
• Industrial machinery
• Telecommunication
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
規格
Attribute | Value |
|---|---|
| Coil Voltage | 12V dc |
| Contact Configuration | DPDT |
| Mounting Type | Surface Mount |
| Maximum Switching Current AC | 4 A |
| Maximum Switching Current DC | 4 A |
| Maximum Switching Voltage AC | 277V |
| Maximum Switching Voltage DC | 220V |
| Series | HFD3 |
| Maximum Switching Power DC | 90 W |
| Latching | No |
| Length | 15mm |
| Depth | 7.5mm |
| Height | 9mm |
| Dimensions | 15 x 7.5 x 8.5mm |
| Terminal Type | SMD Tab |
| Number of Poles | 1 |
| Switching Current | 2A |
| Operating Temperature Range | -40 → +85°C |
| Contact Material | Gold Plated |
| Maximum Switching Power AC | 62.5VA |
| Features | SMT And DIP Types Available, Bifurcated Contacts, Single Side Stable And Latching Type Available |
| Relay Switching Classification | Subminiature Signal Relay |
| Coil Resistance | 1028Ω |
| Electrical Life | 100000 Operations |
| Life | 1 x 10^8 cycles |
| Minimum Operating Temperature | -40°C |
| Isolation Coil To Contact | 1.5kV ac |
| Coil Power | 140mW |
| Maximum Operating Temperature | +85°C |
