Jumo 701514 Panel Mount Digital Indicator, 22 x 89mm 3 Input, 1 Output Relay, 110 → 240 V ac Supply Voltage

The Jumo Universal Applicable Digital Indicator in the small DIN landscape format is suitable for the front installation to display temperature, pressure and other process variables. The version has individual display elements for the switch position of the outputs and also for manual mode, ramp function and timer. The display is operated by a membrane keyboard with four keys and can be used at rough environmental influences because of the high protection type IP65. The digital indicator has a min-max-value-display function, hold-function, tare function, limit value monitoring function, digital control signal, wide timer function an a service counter. With the setup program (included program editor and ST editor) it can be configured with a computer. In the hardware is also a universal input, two relay outputs (normally open contact), a digital input, a digital in- and output and a anlog output included. The voltage supply range is AC 110 to 240 V, 48 to 63 Hz.

Device is characterized by easy and clearly structured with ext-supported operation
Process value and parameters shown on two 18 segment LCD displays
Configuration via USB interface does not require a separate voltage supply
