Microchip Temperature Sensor, Digital Output, Through Hole Mount, Serial-I2C, SMBus, ±3°C, 5 Pins

此圖片僅供參考，請參閲產品詳細資訊及規格

查看此類別
暫時無法供應
我們無法確定此產品何時有貨，RS 預計將其從我們的產品目錄中移除。
RS庫存編號:
738-6005
製造零件編號:
TC74A5-5.0VAT
製造商:
Microchip
透過選取一個或多個屬性來查找類似產品。
選取全部

品牌

Microchip

Sensor Function

Temperature

Output Type

Digital

Interface Type

Serial-I2C, SMBus

Accuracy

±3°C

Mounting Type

Through Hole

Pin Count

5

Operating Temperature Range

-40 → +125 °C

Minimum Operating Temperature

-40 °C

Maximum Operating Temperature

+125 °C

Minimum Operating Supply Voltage

2.7 V

Maximum Operating Supply Voltage

5.5 V

Package Type

TO-220

Length

10.54mm

Height

15.57mm

Width

4.7mm

Dimensions

10.54 x 4.7 x 15.57mm

Resolution

8 bit

COO (Country of Origin):
MY

TC74 Digital Thermal Sensors


The TC74 series of digital thermal sensors convert temperature into digital form through the on-chip thermal sensing element.
The sensors are particularly suited for thermal protection and thermal control applications.


Features;
2Wire serial interface
2.7 V to 5.5 V voltage range

For these non-cancellable (NC), and non-returnable (NR) products, Terms and Conditions apply.



Temperature & Humidity Sensors, Microchip
