Helukabel F-CY Series Control Cable, 4 Pairs, 1.5 mm², Grey Sheath Polyvinyl Chloride

查看此類別

小計（1 卷，共 100 米）*

HK$2,054.50

Add to Basket
選擇或輸入數量
库存信息目前无法访问 - 请稍候查看
卷
每卷
每米*
1 +HK$2,054.50HK$20.545

* 參考價格

RS庫存編號:
361-867
製造零件編號:
16395
製造商:
Helukabel
透過選取一個或多個屬性來查找類似產品。
選取全部

品牌

Helukabel

Product Type

Control Cable

Number of Pairs

4

Cross Sectional Area

1.5 mm²

Jacket Colour

Grey

Conductor Type

Stranded

Jacket Material

Polyvinyl Chloride

Minimum Operating Temperature

-40°C

Maximum Operating Temperature

80°C

Standards/Approvals

DIN VD0285-525-2-51 / DIN EN 50525-2-51 / DIN VD0295 / IEC 60228 / DIN VD0293-334 / DIN VD0207-363-4-1 / DIN EN 50363-4-1 / DIN VD0482-332-1-2 / DIN EN 60332-1-2 / IEC 60332-1-2 / EAC / VDE-Reg.-No. 7034

Fire Behaviour

Flame Retardant

Conductor Material

Copper Wire

Series

F-CY

Voltage

500V

COO (Country of Origin):
DE
The Helukabel PVC Control and connection cable designed for flexible use with free movement without tensile stress or forced movements in dry, moist and wet rooms but not outside, to be used as control and connecting cable in control and regulation technology, in the tool and machine building industry, in computer systems, as well as a signal cable in the electronic industry. A stabilizing foil separator between wire bound and braid reduces the outer diameter essentially and allows for smaller bending radius as well as lower weights. The disturbance free transmission of signals and impulses is ensured due to the high degree of screening.

Oil resistant

Flame retardant

Coupling resistance

EAC and VDE approved
