Belden YE00906 Series Multi-Core Industrial Cable, 2 Pairs, 0.5 mm², 100 m, Green Sheath Low Smoke Zero Halogen

RS庫存編號:: 382-894
製造零件編號:: YE00906.00100
製造商:: Belden

Belden YE00906 Series Multi-Core Industrial Cable, 2 Pairs, 0.5 mm², 100 m, Green Sheath Low Smoke Zero Halogen

小計（1 卷，共 100 米）*

HK$1,483.90

訂單超過 HK$250.00 免費送貨

有庫存

9 件準備從其他地點送貨
加上 7 件從 2026年9月04日起發貨

**需要更多嗎？**輸入您需要的數量，然後按一下「查看送貨日期」以查詢更多庫存和送貨詳細資訊。

卷	每卷	每米*
1 +	HK$1,483.90	HK$14.839

* 參考價格

RS庫存編號:: 382-894
製造零件編號:: YE00906.00100
製造商:: Belden

規格

產品概覽和技術數據資料表

法例與合規

產品詳細資訊

透過選取一個或多個屬性來查找類似產品。

選取全部	屬性	值
	品牌	Belden
	Number of Pairs	2
	Product Type	Multi-Core Industrial Cable
	Cross Sectional Area	0.5 mm²
	Number of Cores	4
	Cable Length	100m
	Jacket Colour	Green
	Outside Diameter	6.3mm
	Conductor Type	Solid
	Jacket Material	Low Smoke Zero Halogen
	Minimum Operating Temperature	-20°C
	Maximum Operating Temperature	70°C
	Standards/Approvals	Euroclass Eca
	Fire Behaviour	FRNC
	Conductor Material	Bare Copper
	Series	YE00906
	Voltage	300V
	Number of Strands	1

	選取全部
	品牌 Belden
	Number of Pairs 2
	Product Type Multi-Core Industrial Cable
	Cross Sectional Area 0.5 mm²
	Number of Cores 4
	Cable Length 100m
	Jacket Colour Green
	Outside Diameter 6.3mm
	Conductor Type Solid
	Jacket Material Low Smoke Zero Halogen
	Minimum Operating Temperature -20°C
	Maximum Operating Temperature 70°C
	Standards/Approvals Euroclass Eca
	Fire Behaviour FRNC
	Conductor Material Bare Copper
	Series YE00906
	Voltage 300V
	Number of Strands 1

COO (Country of Origin):: CN

Belden Green Multicore Industrial Cable, 100m Length, 4 Cores - YE00906.00100

Improve the efficiency of a building's infrastructure with this European Installation Bus cable from Belden. Its solid copper strands are highly conductive to ensure a reliable connection. Thanks to its twisted-pair design and foil shield, this cable ensures reduced noise and interference for clear data transmission. A long cable length of 100m makes it suitable for use in large installations, or you can cut it to size to suit your system's needs.

Features & Benefits

• Low-smoke, zero-halogen sheath to maximise safety in the event of a fire

• Wide operating temperature range between -20°C and +70°C for use in harsh conditions

• Colour-coded conductors to simplify connections

• Polyethylene insulation for protection against abrasion and wear

Applications

• Facilities management

• Building controls

• Industrial communications

What's the diameter of this cable?

This cable has a nominal diameter of 6.3mm, so it can fit into tighter setups.
