D Sub Connectors

D-sub or D-subminiature connectors are common types of electrical components typically used in computing to help form connections on a circuit board. Taking their name from the characteristically designed D shaped metal shield, d-sub connectors have various different connection types from Crimp D-sub's to Spring Terminal D-sub's.



What are the types of D-sub Connectors we offer?




  • PCB (printed circuit board): D-Sub Connectors-Are specially designed D-subs that has built-in solder points to help assist the mounting of the connector on PCB's.

  • Crimp D-sub Connectors: Can help attach several wires to a single receptive connector. You can also use them to connect large cables to standard wire receptive connectors.

  • IDC (insulation displacement contact)D-sub Connectors: Are designed to be connected to the conductor(s) of an insulated cable, most commonly a ribbon cable (a cable with many conducting wires running parallel to each other on the same flat plane).

  • Leaded D-sub Connectors: Are connectors with wires/ leads already attached, ready for connection to boards from purchase.

  • Screw Terminal D-sub Connectors: Are most commonly used in building wiring for the distribution of electricity, for example, connecting electrical switches to the mains, or to connect major appliances such as ovens.

  • Solder D-sub Connectors: As their name suggests, solder D-sub connectors are designed to be connected into your circuit using solder and a soldering iron.

  • Spring Terminal D-sub Connectors: Create an electrical connection that's established by clamping individual stripped wires or cables using a spring.

  • Wire Wrap D-sub Connectors: are connected to PCBs (printed circuit boards) using wires wrapped around the connectors' wire posts.

  • D-sub Connector Kits: D-sub connector kits usually have nuts that accept screws and are used to lock the components together and offer mechanical strain relief. Hood- the exterior shell/casing of the connector, usually made from a hard and durable metal such as zinc. Screws and inserts for securing parts together.


...
顯示內容 隱藏內容

篩選條件

正在檢視 461 - 480,共 4391 項產品
Results per page
Description Price Number of Contacts Gender Body Orientation Mounting Type Pitch CAD Drawing D Connector Type D-Sub Shell Size Mounting Hardware Termination Method Current Rating Mixed Contact Layout Housing Material Voltage Rating
RS庫存編號 162-0506
製造零件編號L77D B25S ST4
BrandAmphenol
HK$200.928
個 (以毎袋:32)
單位
25 - Straight Cable Mount - - - - - Screw Terminal - - Steel -
RS庫存編號 375-2372
製造零件編號119998-3057
BrandITT Cannon
HK$50.52
/個 (每包:5個)
單位
25 Female Right Angle Through Hole 2.77mm - - - - Solder 5.0A - Thermoplastic -
RS庫存編號 173-8618
製造零件編號D37S24A4GV00LF
HK$33.37
Each (In a Tray of 15)
單位
37 Female Straight Through Hole 2.76mm - - - - Solder 5.0A - PBT 300.0 V
RS庫存編號 270-9743
製造零件編號748364-1
HK$21.22
單位
15 Male Straight Cable Mount - - - - - Crimp 1.9A - Steel 250 V ac
RS庫存編號 542-7422
製造零件編號DA3V3PA00LF
HK$15.69
單位
3 (Power) - - Cable Mount - - - - - - - - - -
RS庫存編號 771-8269
製造零件編號618025227221
HK$73.77
單位
25 Female Straight Cable Mount 2.77 mm, 2.84mm - - - - IDC 3.0A - Steel 250 V ac
RS庫存編號 121-7382
製造零件編號865625SLTLF
HK$6.128
個 (以毎盒:100)
單位
25 Female Straight Cable Mount 2.76mm - - - - Crimp 5.0A - Steel 1.0 kV
RS庫存編號 612-6653
製造零件編號MWDM2L-37SCBRP-.110
BrandGlenair
HK$3,374.51
單位
37 Female Right Angle Through Hole 2.54mm - - - - Solder 3.0A - Aluminium Alloy -
RS庫存編號 476-508
製造零件編號516-290-541
BrandEDAC
HK$304.83
毎包:100 個
Bag(s)
- Female Straight - - - - - - - 8.5A - - -
RS庫存編號 787-3767
製造零件編號MHD45PPK9-DB9P-K
HK$11.49
單位
9 - 45 ° - - - - - - Solder - - Plastic -
RS庫存編號 544-3979
BrandRS PRO
HK$20.13
單位
15 Female Right Angle Through Hole - - - - - Solder 3A - Thermoplastic 350 V dc
RS庫存編號 674-0874
製造零件編號A-DFF 25LPIII/FP
HK$24.37
單位
25 Female Right Angle Cable Mount 2.54mm - - - - IDC 5.0A - Plastic -
RS庫存編號 719-5786
製造零件編號DBC15SS-NW
HK$6.52
/個 (每包:5個)
單位
15 Female Straight Cable Mount 2.77mm - - - - Crimp 5.0A - Steel 250 V ac
RS庫存編號 771-8278
製造零件編號61800924923
HK$16.53
單位
9 Female Straight Cable Mount 2.77 mm, 2.84mm - Standard D-Sub E - Solder 3.0A - Steel 125 V ac
RS庫存編號 612-6388
製造零件編號MWDM2L-37SS
BrandGlenair
HK$800.05
單位
37 Female Straight Panel Mount - - Micro-D - - Solder 3.0A - Aluminium -
RS庫存編號 162-0511
製造零件編號L77D E09S ST3
BrandAmphenol
HK$105.17
個 (以毎袋:25)
單位
9 Female Straight Panel Mount - - - - - Screw Terminal 7.5A - Steel 300.0 V
RS庫存編號 782-9485
製造零件編號749805-9
HK$163.48
單位
25 - Straight Cable Mount - - - - - Crimp - - Nylon -
RS庫存編號 922-9654
製造零件編號09652217701
BrandHARTING
HK$31.32
個 (以毎盒:100)
單位
15 Male Straight Through Hole 2.74mm - - - M3 Threaded Inserts Solder 7.5A - Steel -
RS庫存編號 821-2844
製造零件編號MHDM37SP
HK$43.61
單位
37 Male Straight Cable Mount 2.77mm - Standard D-Sub C - Solder 5.0A - Steel -
RS庫存編號 171-1402
製造零件編號119998-3057
BrandITT Cannon
HK$40.043
/個 (每包:1000個)
單位
25 Female Right Angle Through Hole 2.77mm - - - - Solder 5.0A - Thermoplastic -
