C8051F388-B-GQ | Silicon Labs, 8bit 8051, C8051F Microcontroller, 48MHz, 64 kB Flash, 48-Pin TQFP | RS

Silicon Labs, 8bit 8051, C8051F Microcontroller, 48MHz, 64 kB Flash, 48-Pin TQFP

RS庫存編號:: 819-6869P
製造零件編號:: C8051F388-B-GQ
製造商:: Silicon Labs

Silicon Labs, 8bit 8051, C8051F Microcontroller, 48MHz, 64 kB Flash, 48-Pin TQFP

此產品已停售

RS庫存編號:: 819-6869P
製造零件編號:: C8051F388-B-GQ
製造商:: Silicon Labs

Datasheet

Attribute	Value
Family Name	C8051F
Package Type	TQFP
Mounting Type	Surface Mount
Pin Count	48
Device Core	8051
Data Bus Width	8bit
Program Memory Size	64 kB
Maximum Frequency	48MHz
RAM Size	4.352 kB
USB Channels	0
Number of PWM Units	1 x 16 bit
Number of SPI Channels	1
Typical Operating Supply Voltage	3.3 V
Number of UART Channels	2
Number of CAN Channels	0
Number of USART Channels	0
Number of I2C Channels	2
Maximum Operating Temperature	+85 °C
Number of PCI Channels	0
Dimensions	7 x 7 x 1.05mm
Height	1.05mm
Minimum Operating Temperature	-40 °C
Pulse Width Modulation	1 (5 x 16 bit)
Number of Ethernet Channels	0
Width	7mm
Maximum Number of Ethernet Channels	0
Instruction Set Architecture	MCU
ADCs	32 x 10 bit
Number of LIN Channels	0
Number of ADC Units	1
Length	7mm
Program Memory Type	Flash

Silicon Labs, 8bit 8051, C8051F Microcontroller, 48MHz, 64 kB Flash, 48-Pin TQFP

C8051F3xx Microcontollers, Silicon Labs
