Geckodrive 0.01 kW Stepper Motor Controller, 80V dc, 2 Phase, 7A

查看所有Motor Controllers

小計（1 件）*

HK$2,078.80

Add to Basket
選擇或輸入數量
有庫存
  • 加上 15 件從 2026年7月27日 起發貨
  • 加上 5 件從 2026年9月02日 起發貨
**需要更多嗎？**輸入您需要的數量，然後按一下「查看送貨日期」以查詢更多庫存和送貨詳細資訊。
單位
每單位
1 +HK$2,078.80

* 參考價格

RS庫存編號:
793-4121
製造零件編號:
G203V
製造商:
Geckodrive
透過選取一個或多個屬性來查找類似產品。
選取全部

品牌

Geckodrive

Product Type

Stepper Motor Controller

Number of Phases

2

Output Voltage

80V dc

Supply Voltage

80V dc

Current Rating

7A

Power Rating

0.01kW

Overall Length

63.5mm

Overall Width

21mm

Overall Depth

65.5mm

Minimum Operating Temperature

0°C

Maximum Operating Temperature

70°C

Standards/Approvals

No

COO (Country of Origin):
US

G203V - Stepper Drive


The G203V is the new generation CPLD-based microstep drive. It has short-circuit protection for the motor outputs, over-voltage and under-voltage protection, over-temperature protection, reversed power supply polarity protection and will survive accidental motor disconnects while powered-up. The “V” in G203V stands for “Vampire” as it is an unkillable drive.

The G203V uses a synchronous PWM design that is absolutely silent when the motor is stopped or turning slowly. It virtually eliminates stopped-motor heating regardless of power supply voltage. The G203V is a jumper-free drive. There are no internal user settings at all so there is no need to ever remove the drive cover at all.

STEP, DIRECTION and DISABLE inputs are opto-isolated

These inputs are +2.5/3.3/5 VDC compatible

Direction is clocked in on the active step pulse edge

Needs heatsinking for current settings greater than 3 amps

LED-status indicators

Power supply voltage between 15 and 80 VDC
