Keysight Technologies Truevolt 34460A Bench Digital Multimeter True RMS

RS庫存編號:: 777-7101
Distrelec 貨號:: 110-41-943
製造零件編號:: 34460A
製造商:: Keysight Technologies

Keysight Technologies Truevolt 34460A Bench Digital Multimeter True RMS

此圖片僅供參考，請參閲產品詳細資訊及規格

小計（1 件）*

HK$10,729.50

訂單超過 HK$250.00 免費送貨

庫存資訊目前無法查詢

單位	每單位
1 +	HK$10,729.50

* 參考價格

RS庫存編號:: 777-7101
Distrelec 貨號:: 110-41-943
製造零件編號:: 34460A
製造商:: Keysight Technologies

規格

產品概覽和技術數據資料表

法例與合規

產品詳細資訊

透過選取一個或多個屬性來查找類似產品。

選取全部	屬性	值
	品牌	Keysight Technologies
	Product Type	Multimeter
	Multimeter Type	Bench
	Display Type	Digital
	Model Number	Truevolt 34460A
	Functions Measured	DC Current, AC Voltage, AC Current, Temperature, DC Voltage, Resistance
	Maximum DC Voltage Measurement	1000V
	True RMS	Yes
	AC Voltage Accuracy	±4 % rdg + 0.5
	AC Current Accuracy	±0.23 % rdg + 0.04
	Maximum Frequency	300kHz
	Minimum Operating Temperature	0°C
	Battery Life	10year
	Maximum Operating Temperature	55°C
	Height	103.8mm
	Width	216.2 mm
	Weight	3.7kg
	Standards/Approvals	No
	Length	303.2mm
	Safety Category Level	CAT II
	Battery Type	CR302
	Safety Category Voltage	300V

	選取全部
	品牌 Keysight Technologies
	Product Type Multimeter
	Multimeter Type Bench
	Display Type Digital
	Model Number Truevolt 34460A
	Functions Measured DC Current, AC Voltage, AC Current, Temperature, DC Voltage, Resistance
	Maximum DC Voltage Measurement 1000V
	True RMS Yes
	AC Voltage Accuracy ±4 % rdg + 0.5
	AC Current Accuracy ±0.23 % rdg + 0.04
	Maximum Frequency 300kHz
	Minimum Operating Temperature 0°C
	Battery Life 10year
	Maximum Operating Temperature 55°C
	Height 103.8mm
	Width 216.2 mm
	Weight 3.7kg
	Standards/Approvals No
	Length 303.2mm
	Safety Category Level CAT II
	Battery Type CR302
	Safety Category Voltage 300V

登入下載 CAD 模型

不適用

COO (Country of Origin):: MY

Keysight Technologies Multimeter, 100Ω to 100MΩ Resistance Measurement Range, 3Hz to 300kHz Frequency Measurement Range - Truevolt Series - 34460A

Put the power of precision into your hands with this multimeter from Keysight Technologies. This bench-type device measures electrical values such as AC current, DC voltage and resistance, so it's a versatile piece of kit. A Basic DCV accuracy of 75ppm ensures precise readings, avoiding the need for repeated measurements. A 4.3-inch LED-backlit display means you can view data on histograms and bar charts with ease. BenchVue Software provides an all-in-one solution for logging your data and controlling your multimeter from the comfort of your PC.

Features & Benefits

• Broad operating temperature range between 0°C and +55°C for use in extreme environments

• Compact dimensions of 303.2 (L) x 216.2 (W) x 103.8mm (H) to fit comfortably in tight setups

• Light weight of 3.7kg to place minimal strain on your setup

Applications

• Industrial automation

• Electronic equipment testing

• Fault diagnosis

What does True RMS mean?

True RMS is a type of multimeter measurement that provides the equivalent DC Value of an AC waveform. It's particularly useful for measuring non-sinusoidal waveforms, which are common in many modern electronic devices.

Note

Manufacturer’s Warranty

Standards

ISO/IEC 17025

Supplied with

Power cord, calibration certificate
