Rohde & Schwarz RTM3000 Series, 1 GHz Bench Oscilloscope, 16 Channels
- RS庫存編號:
- 174-2858
- Distrelec 貨號:
- 301-01-723
- 製造零件編號:
- RTM3K-102M
- 製造商:
- Rohde & Schwarz
小計（1 件）*
HK$168,424.80
訂單超過 HK$250.00 免費送貨
製造商存貨
- 準備從 2026年6月29日 起發貨
**需要更多嗎？**輸入您需要的數量，然後按一下「查看送貨日期」以查詢更多庫存和送貨詳細資訊。
單位 | 每單位 |
|---|---|
| 1 + | HK$168,424.80 |
* 參考價格
- RS庫存編號:
- 174-2858
- Distrelec 貨號:
- 301-01-723
- 製造零件編號:
- RTM3K-102M
- 製造商:
- Rohde & Schwarz
規格
產品概覽和技術數據資料表
法例與合規
產品詳細資訊
透過選取一個或多個屬性來查找類似產品。
選取全部 | 屬性 | 值 |
|---|---|---|
| 品牌 | Rohde & Schwarz | |
| Product Type | Oscilloscope | |
| Bandwidth | 1GHz | |
| Number of Channels | 16 | |
| Oscilloscope Type | Bench | |
| Oscilloscope Form | Mixed Signal | |
| Interface Type | CAN, IIC, LIN, RS232, RS422, RS485, SPI, UART, USB | |
| Screen Size | 10.1 in | |
| Series | RTM3000 | |
| Width | 390mm | |
| Depth | 152mm | |
| Standards/Approvals | No | |
| Height | 220mm | |
| Plug Type | Type A - North American/Japanese 2-Blade | |
| Power Source | Mains | |
| Safety Category Voltage | 1000V | |
| Safety Category Level | CAT III | |
| Display Type | Capacitive Touch Display | |
| Minimum Vertical Sensitivity | 0.5mV/div | |
| Maximum Time Base | 500s/div | |
| Rise Time | 350ps | |
| Maximum Vertical Sensitivity | 10V/div | |
| Vertical Resolution | 10 bit, 16 bit HD | |
| Minimum Time Base | 0.5ns/div | |
| 選取全部 | ||
|---|---|---|
品牌 Rohde & Schwarz | ||
Product Type Oscilloscope | ||
Bandwidth 1GHz | ||
Number of Channels 16 | ||
Oscilloscope Type Bench | ||
Oscilloscope Form Mixed Signal | ||
Interface Type CAN, IIC, LIN, RS232, RS422, RS485, SPI, UART, USB | ||
Screen Size 10.1 in | ||
Series RTM3000 | ||
Width 390mm | ||
Depth 152mm | ||
Standards/Approvals No | ||
Height 220mm | ||
Plug Type Type A - North American/Japanese 2-Blade | ||
Power Source Mains | ||
Safety Category Voltage 1000V | ||
Safety Category Level CAT III | ||
Display Type Capacitive Touch Display | ||
Minimum Vertical Sensitivity 0.5mV/div | ||
Maximum Time Base 500s/div | ||
Rise Time 350ps | ||
Maximum Vertical Sensitivity 10V/div | ||
Vertical Resolution 10 bit, 16 bit HD | ||
Minimum Time Base 0.5ns/div | ||
Rohde & Schwarz RTM3000 Series RTM3002 Oscilloscope
The Rohde & Schwarz RTM3000 digital oscilloscope is designed with high vertical sensitivity and can perform multiple functions. It allows a bandwidth of 1GHz (1000MHz), memory depth up to 40MS and sampling rate up to 5GS/s. It has a 10 bit analogue to digital converter that offers sharper waveforms with more signal details. This oscilloscope has a large capacitive touch display of 10.1in with a high resolution of 1280 x 800 pixels. It has two analogue channels and performs multiple functions like logical and protocol analyser, waveform and pattern generator for quick and efficient analysis. This oscilloscope also acts as digital voltmeter for simultaneous and precise measurements. This instrument is an ideal choice for the power signal details up to 10 bit resolution.
Features and Benefits
• Allows multiple functions with software licence such as bandwidth upgrade and spectrum and analysis
• Includes probe interface suitable for all Rohde & Schwarz probes
• Touchscreen display with gesture support as like smartphones
• Built-in logical analyser
Applications
• Educational institutes
• Used by service technicians
• R&D troubleshooting
• Production testing
