Hongfa Europe GMBH PCB Mount Signal Relay, 24V dc Coil, 3A Switching Current, DPDT
- RS庫存編號:
- 176-2699
- 製造零件編號:
- HFD2/024-S-D
- 製造商:
- Hongfa Europe GMBH
查看所有Signal Relays
當前暫無庫存，可於2023/7/20發貨，3 工作日送達。
單價 毎管：25 個
原價 HK$22.386
您付款
HK$20.395
| 單位 | Per unit | Per Tube* |
| 25 - 25 | HK$20.395 | HK$509.875 |
| 50 - 75 | HK$19.885 | HK$497.125 |
| 100 + | HK$19.579 | HK$489.475 |
| * 參考價格 | ||
- RS庫存編號:
- 176-2699
- 製造零件編號:
- HFD2/024-S-D
- 製造商:
- Hongfa Europe GMBH
- COO (Country of Origin):
- CN
產品概覽和技術數據資料表
法例與合規
- COO (Country of Origin):
- CN
產品詳細資訊
Hongfa DPDT Non-Latching Relay
The Hongfa DPDT non-latching electromagnetic PCB mount relay is a subminiature form power relay of intermediate category. It is actuated with the help of a 24VDC coil and up to 3A DC/AC current through the coil for the relay to switch positions. It has a low mounting height of 15.3mm. This relay has gold coated silver contacts. Forcibly guided contact is used for guided protection.
Features and Benefits
• Power switching up to 90W in case of DC
• Sensitive coil power of 150mW
• Service temperature range between -40°C and 85°C
• Isolation voltage between coil and contact is 1.5KVAC
• High contact capacity of 2A 30VDC
• Single side stable type relay
• Available in DIP terminal type
• Sensitive coil power of 150mW
• Service temperature range between -40°C and 85°C
• Isolation voltage between coil and contact is 1.5KVAC
• High contact capacity of 2A 30VDC
• Single side stable type relay
• Available in DIP terminal type
Applications
• Used as a control device
• Automotive industry
• Automotive industry
For products that are Customized and under Non-cancellable & Non-returnable, Sales & Conditions apply.
規格
| Attribute | Value |
| Coil Voltage | 24V dc |
| Contact Configuration | DPDT |
| Mounting Type | PCB Mount |
| Maximum Switching Current AC | 2 A |
| Maximum Switching Current DC | 3 A |
| Maximum Switching Voltage AC | 250V |
| Maximum Switching Voltage DC | 220V |
| Maximum Switching Power DC | 90 W |
| Series | HFD2 |
| Length | 20.2mm |
| Latching | No |
| Depth | 10.2mm |
| Height | 10.6mm |
| Dimensions | 20.2 x 10.2 x 10.6mm |
| Terminal Type | PCB Pin |
| Switching Current | 3A |
| Number of Poles | 2 |
| Maximum Switching Power AC | 125VA |
| Coil Resistance | 3800Ω |
| Minimum Operating Temperature | -40°C |
| Contact Material | Gold Plated |
| Coil Power | 150mW |
| Electrical Life | 100000 Operations |
| Features | Bifurcated Contacts, High Sensitive, High Switching Capacity |
| Life | 1 x 10^8 cycles |
| Relay Switching Classification | Subminiature DIP Relay |
| Maximum Operating Temperature | +85°C |
| Operating Temperature Range | -40 → +85°C |
