RS PRO Solid State Interface Relay, 240 Vac Control, 500 mAdc Load, DIN Rail Mount

RS庫存編號:: 212-5495
製造商:: RS PRO

RS PRO Solid State Interface Relay, 240 Vac Control, 500 mAdc Load, DIN Rail Mount

小計（1 件）*

HK$211.50

訂單超過 HK$250.00 免費送貨

有庫存

6 件準備從其他地點送貨
加上 15 件從 2026年2月24日起發貨

**需要更多嗎？**輸入您需要的數量，然後按一下「查看送貨日期」以查詢更多庫存和送貨詳細資訊。

單位	每單位
1 +	HK$211.50

* 參考價格

RS庫存編號:: 212-5495
製造商:: RS PRO

規格

產品概覽和技術數據資料表

法例與合規

產品詳細資訊

透過選取一個或多個屬性來查找類似產品。

選取全部	屬性	值
	品牌	RS PRO
	Maximum Control Voltage	240 Vac
	Maximum Load Current	500 mAdc
	Mounting Type	DIN Rail
	Maximum Load Voltage	48 Vdc
	Minimum Control Voltage	200 Vac
	Control Voltage Range	200 → 240 Vac
	Load Voltage Range	3 → 48 Vdc
	Minimum Load Voltage	3 Vdc
	Width	67.5mm
	Depth	6.1mm
	Series	RS PRO
	Rise Time	50ms
	Length	60.8mm
	Maximum Operating Temperature	+60°C
	Minimum Operating Temperature	-25°C
	Isolation Voltage	2500V
	Dimensions	60.8 x 67.5 x 6.1mm
	Operating Temperature Range	-25 → +60°C
	Manufacturer Part No.	RE-0564 + DMERC-BK

	選取全部
	品牌 RS PRO
	Maximum Control Voltage 240 Vac
	Maximum Load Current 500 mAdc
	Mounting Type DIN Rail
	Maximum Load Voltage 48 Vdc
	Minimum Control Voltage 200 Vac
	Control Voltage Range 200 → 240 Vac
	Load Voltage Range 3 → 48 Vdc
	Minimum Load Voltage 3 Vdc
	Width 67.5mm
	Depth 6.1mm
	Series RS PRO
	Rise Time 50ms
	Length 60.8mm
	Maximum Operating Temperature +60°C
	Minimum Operating Temperature -25°C
	Isolation Voltage 2500V
	Dimensions 60.8 x 67.5 x 6.1mm
	Operating Temperature Range -25 → +60°C
	Manufacturer Part No. RE-0564 + DMERC-BK

登入下載 CAD 模型

COO (Country of Origin):: TW

RS PRO DIN Rail Mount Optocouplers

RS PRO DIN Mount Optocouplers are designed to drive a signal from one electrical circuit to another. By using just light to provide isolation between an input source and an output load, it offers phenomenal levels of optic coupling isolation. This prevents electrical interference and results in a fast switching frequency for your precise requirements.

Features and Benefits

• DIN rail mount optocoupler

• LED input

• Highly precise with 10 times faster switching capacity

• Slim design

• Resistant to dust and humidity

• Operating temperature range of -25°C to +60°C

• Dimensions of 60.8 mm x 67.5 mm x 6.1 mm

• RoHS (Restriction of Hazardous Substances) compliant

RS PRO DIN Rail Mount Optocoupler Options

RS PRO Optocoupler series are available with a range of different rated input voltages and currents, all offering a quick frequency switching connection:

• Rated input voltage, 5V DC & 15 - 18mA; RS Stock no: 212-5492

• Rated input voltage, 5V DC & 10 - 15mA; RS Stock no: 212-5496

• Rated input voltage, 24V DC & 12 -14mA; RS Stock no: 212-5493

• Rated input voltage, 24 VDC & 10 - 15mA; RS Stock no: 212-5497

• Rated input voltage, 95 - 125V AC & 0.6 - 1.3mA; RS Stock no: 212-5494

• Rated input voltage, 90 - 265V AC & 10mA; RS Stock no: 212-5499

• Rated input voltage, 200 - 240V AC & 0.6 - 1.1mA; RS Stock no: 212-5495

Applications

RS PRO optocoupler can be used in a wide range of applications such as;

• Communications equipment

• Process automation

• Machine controls
