產品詳細資訊

透過選取一個或多個屬性來查找類似產品。

選取全部	屬性	值
	品牌	Renesas Electronics
	Family Name	S3A1
	Package Type	LQFP
	Mounting Type	Surface Mount
	Pin Count	144
	Device Core	ARM Cortex M4
	Data Bus Width	32bit
	Program Memory Size	1 MB
	Maximum Frequency	48MHz
	RAM Size	192 kB
	USB Channels	1
	Number of PWM Units	0
	Number of SPI Channels	2
	Typical Operating Supply Voltage	1.6 → 5.5 V
	Number of USART Channels	0
	Number of CAN Channels	1
	Number of I2C Channels	3
	Number of UART Channels	1
	Number of LIN Channels	0
	Length	20.1mm
	Number of ADC Units	1
	ADCs	28 x 14 bit
	Maximum Operating Temperature	+105 °C
	Program Memory Type	Flash
	Number of PCI Channels	0
	Maximum Number of Ethernet Channels	0
	Height	1.55mm
	Instruction Set Architecture	DSP
	Minimum Operating Temperature	-40 °C
	Dimensions	20.1 x 20.1 x 1.55mm
	Number of Ethernet Channels	0
	Width	20.1mm

	選取全部
	品牌 Renesas Electronics
	Family Name S3A1
	Package Type LQFP
	Mounting Type Surface Mount
	Pin Count 144
	Device Core ARM Cortex M4
	Data Bus Width 32bit
	Program Memory Size 1 MB
	Maximum Frequency 48MHz
	RAM Size 192 kB
	USB Channels 1
	Number of PWM Units 0
	Number of SPI Channels 2
	Typical Operating Supply Voltage 1.6 → 5.5 V
	Number of USART Channels 0
	Number of CAN Channels 1
	Number of I2C Channels 3
	Number of UART Channels 1
	Number of LIN Channels 0
	Length 20.1mm
	Number of ADC Units 1
	ADCs 28 x 14 bit
	Maximum Operating Temperature +105 °C
	Program Memory Type Flash
	Number of PCI Channels 0
	Maximum Number of Ethernet Channels 0
	Height 1.55mm
	Instruction Set Architecture DSP
	Minimum Operating Temperature -40 °C
	Dimensions 20.1 x 20.1 x 1.55mm
	Number of Ethernet Channels 0
	Width 20.1mm

synergy-s3a1-datasheet

The MCU integrates multiple series of software- and pin-compatible Arm®-based 32-bit MCUs that share a common set of Renesas peripherals to facilitate design scalability and efficient platform-based product development. The MCU provides an optimal combination of low-power, high-performance Arm Cortex®-M4 core running up to 48 MHz,

1-MB code flash memory
192-KB SRAM
Segment LCD Controller (SLCDC)
Capacitive Touch Sensing Unit (CTSU)
USB 2.0 Full-Speed Module (USBFS)
14-bit A/D Converter (ADC14)
12-bit D/A Converter (DAC12)
Security features.

單位	每單位	每托盤*
25 - 25	HK$98.316	HK$2,457.90
50 - 75	HK$95.856	HK$2,396.40
100 +	HK$94.384	HK$2,359.60

Renesas Electronics, 32bit ARM Cortex M4, S3A1 Microcontroller, 48MHz, 1 MB Flash, 144-Pin LQFP
