Name: Microchip, 8 bit PIC, PIC16F1828 Microcontroller, 32 MHz, 7kB FLASH, 20-Pin SSOP
Brand: Microchip
SKU: 887-7224
Price: 22.85 HKD
Availability: OutOfStock

規格

產品概覽和技術數據資料表

法例與合規

產品詳細資訊

透過選取一個或多個屬性來查找類似產品。

選取全部	屬性	值
	品牌	Microchip
	Series	PIC16F1828
	Product Type	Microcontroller
	Package Type	SSOP
	Mount Type	Surface
	Pin Count	20
	Device Core	PIC
	Data Bus Width	8bit
	Interface Type	EUSART, I2C, SPI
	Program Memory Size	7kB
	Maximum Clock Frequency	32MHz
	RAM Size	512bit
	Maximum Supply Voltage	5.5V
	Analogue Comparators	2
	Number of Programmable I/Os	18
	Maximum Power Dissipation Pd	800mW
	Minimum Operating Temperature	-40°C
	Maximum Operating Temperature	85°C
	Length	7.2mm
	Standards/Approvals	No
	Height	1.75mm
	Width	5.3 mm
	Minimum Supply Voltage	1.8V
	Automotive Standard	No
	ADCs	12 x 10 Bit
	Program Memory Type	FLASH
	Number of Timers	5
	Instruction Set Architecture	RISC

	選取全部
	品牌 Microchip
	Series PIC16F1828
	Product Type Microcontroller
	Package Type SSOP
	Mount Type Surface
	Pin Count 20
	Device Core PIC
	Data Bus Width 8bit
	Interface Type EUSART, I2C, SPI
	Program Memory Size 7kB
	Maximum Clock Frequency 32MHz
	RAM Size 512bit
	Maximum Supply Voltage 5.5V
	Analogue Comparators 2
	Number of Programmable I/Os 18
	Maximum Power Dissipation Pd 800mW
	Minimum Operating Temperature -40°C
	Maximum Operating Temperature 85°C
	Length 7.2mm
	Standards/Approvals No
	Height 1.75mm
	Width 5.3 mm
	Minimum Supply Voltage 1.8V
	Automotive Standard No
	ADCs 12 x 10 Bit
	Program Memory Type FLASH
	Number of Timers 5
	Instruction Set Architecture RISC

PIC16F627A/628A/648A Microcontrollers

The PIC16F range of Microcontrollers from Microchip are 8-bit MCUs that incorporate Microchip’s PIC® architecture into a variety of pin and package options, from space efficient 14-pin devices to feature-rich 64-pin devices. Devices with Baseline, Mid-Range or Enhanced Mid-Range architecture are available with numerous different peripheral combinations, giving designers flexibility and choice for their applications.

The PIC16F627A/628A/648A family of Microcontrollers is based upon Microchip’s Mid-Range core with an 8 level deep hardware stack and 35 instructions. These MCUs provide up to 5 MIPS, up to 3.5 Kbytes program memory, 224 bytes RAM and Data EEPROM of up to 128 bytes. On board is an oscillator factory calibrated to ±1% accuracy.

Microcontroller Features

20 MHz Max. CPU Speed

35 Instructions

8 Level Hardware Stack

16 I/O Pins

Power-On Reset (POR)

Power-Up Timer (PWRT)

Oscillator Start-Up Timer (OST)

Brown-Out Reset (BOR)

Watchdog Timer (WDT)

Low Voltage Programming (LVP)

In-Circuit Serial Programming (ICSP)

Peripherals

Two Comparators

Capture/Compare/PWM Module

Two 8-bit Timers

One 16-bit Timer

單位	每單位	每管*
42 - 42	HK$22.848	HK$959.62
84 - 378	HK$22.39	HK$940.38
420 +	HK$21.719	HK$912.20
