產品詳細資訊

透過選取一個或多個屬性來查找類似產品。

選取全部	屬性	值
	品牌	Intelligent LED Solutions
	Product Type	Sensor Development Tool
	Featured Device	SFH 7070
	For Use With	Wearable Devices, Mobile Devices, Fitness Trackers, Smart Watches
	Standards/Approvals	RoHS
	Kit Name	BIOFY Sensor Version 1.1

	選取全部
	品牌 Intelligent LED Solutions
	Product Type Sensor Development Tool
	Featured Device SFH 7070
	For Use With Wearable Devices, Mobile Devices, Fitness Trackers, Smart Watches
	Standards/Approvals RoHS
	Kit Name BIOFY Sensor Version 1.1

Datasheet

COO (Country of Origin):: GB

At the heart of each Biofy® Eco1 is a Biofy® SFH7070 sensor. The SFH7070 consists of a large-format photo diode and three green LEDs with a wavelength of 530 nanometres (nm). It is used for monitoring heart rate by measuring the volume of blood passing through blood vessels. It works by shining light on the surface of the skin.

Different amounts of this light are absorbed by blood and the surrounding tissue. The light not absorbed is reflected to the detector. With its green emission spectrum the SFH7070 is ideal for measuring the pulse rate at the wrist. Eco1s are compact, powerful LED light sources built on FR4 PCB with thermal vias for optimal thermal management. Biofy® Eco1s generate very little heat and therefore do not require any secondary Heat Sinking.

Biofy® Eco1s contain a Biofy® SFH7070 Sensor*

Mounting holes using M3 screws allows easy installation

Size (LxWxH): 20.25x13.70x0.90mm

SFH7070 Contains 2 x Green LED 530nm 1 x Detector with a spectral range sensitivity of 402...694nm

單位	每單位
1 - 9	HK$80.20
10 - 24	HK$77.00
25 +	HK$73.80

Intelligent LED Solutions BIOFY Sensor Version 1.1 for SFH 7070 Wearable Devices, Mobile Devices, Fitness Trackers,
